Core lock stopper blocks / wedge-shaped / internal thread / inclined bolt mounting / full groove embedding / large version
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| ALBPS10-T[30,35,40,50]-W[48,58,68]-E[10-40/1]-A[10-20/1]-G[12-25/1] |
| ALBPS13-T[35,40,50,60]-W[48,58,68,78]-E[10-50/1]-A[10-20/1]-G[12-25/1] |
| ALBPS16-T[35,40,50,60]-W[58,68,78]-E[10-50/1]-A[10-20/1]-G[12-25/1] |
| ALBPS20-T[40,50,60]-W[58,68,78]-E[10-50/1]-A[10-20/1]-G[12-25/1] |
| Part Number | Minimum order quantity | Volume Discount | RoHS | T (Block height) (mm) | A/W (Block width) (mm) | H/E (Inlay part dimension) (mm) | D (Angular hole dia.) (mm) | A (Angle) (°) | G (Angle) (°) | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Quote | 10 | 30 ～ 50 | 48 ～ 68 | 10 ～ 40 | 10 | 10 ～ 20 | 12 ～ 25 | ||
| 1 | Quote | 10 | 35 ～ 60 | 48 ～ 78 | 10 ～ 50 | 13 | 10 ～ 20 | 12 ～ 25 | ||
| 1 | Quote | 10 | 35 ～ 60 | 58 ～ 78 | 10 ～ 50 | 16 | 10 ～ 20 | 12 ～ 25 | ||
| 1 | Quote | 10 | 40 ～ 60 | 58 ～ 78 | 10 ～ 50 | 20 | 10 ～ 20 | 12 ～ 25 |
Loading...
Basic information
| Product type | Inlay type | Material | O1 Tool Steel | Bolt fixing | PL installation |
|---|---|---|---|---|---|
| Oil groove | Non-oil groove | With/without angular hole | Yes | K (Locking angle)(°) | 0 |
| Shape | ④ |
Configure
Basic Attributes
-
T (Block height)(mm)
-
A/W (Block width)(mm)
-
H/E (Inlay part dimension)(mm)
-
D (Angular hole dia.)(mm)
-
A (Angle)(°)
-
G (Angle)(°)
-
Type
- ALBPS
-
Filter by CAD data type
- 2D
- 3D
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
