Bushes for sprue locks / bore selectable
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| RLBS3-10 |
| RLBS3-15 |
| RLBS4-10 |
| RLBS4-15 |
| RLBS4-25 |
| RLBS5-10 |
| RLBS6-15 |
| RLBS6-20 |
| RLBS6-25 |
| RLBS6-30 |
| RLBS8-25 |
| RLBST2-[15-25/5]-A[2.5-3.5/0.5]-V[2.5-4/0.5] |
| RLBST2-LC[15.1-24.9/0.1]-A[2.5-3.5/0.5]-V[2.5-4/0.5] |
| RLBST3-[10-25/5]-A[3.5-4.5/0.5]-V[3.5-5/0.5] |
| RLBST3-LC[10.1-24.9/0.1]-A[3.5-4.5/0.5]-V[3.5-5/0.5] |
| RLBST4-[15-25/5]-A[4.5-6.5/0.5]-V[4.5-7/0.5] |
| RLBST4-LC[15.1-24.9/0.1]-A[4.5-6.5/0.5]-V[4.5-7/0.5] |
| RLBST5-[15-25/5]-A[5.5-6.5/0.5]-V[5.5-7/0.5] |
| RLBST5-LC[15.1-24.9/0.1]-A[5.5-6.5/0.5]-V[5.5-7/0.5] |
| RLBST6-[15-30/5]-A[6.5-8.5/0.5]-V[6.5-9/0.5] |
| RLBST6-LC[15.1-29.9/0.1]-A[6.5-8.5/0.5]-V[6.5-9/0.5] |
| RLBST8-[15-30/5]-A[8.5-11.5/0.5]-V[8.5-12/0.5] |
| RLBST8-LC[15.1-29.9/0.1]-A[8.5-11.5/0.5]-V[8.5-12/0.5] |
| RLBT4-15 |
| RLBT4-20 |
| RLBT4-25 |
| RLBT4-[10,15,20,25] |
| RLBT5-10 |
| RLBT5-15 |
| RLBT5-20 |
| RLBT5-25 |
| RLBT5-[10,15,20,25] |
| RLBT6-15 |
| RLBT6-20 |
| RLBT6-25 |
| RLBT6-[15,20,25] |
| RLBT8-[15,20,25] |
| RLBT10-25 |
| Part Number | Minimum order quantity | Volume Discount | RoHS | Bushing tip shape | Alterations | Applicable runner lock pin diameter (mm) | L (L dimension) (mm) | A (Tip diameter) (mm) | LC (L dimension alteration) (mm) | V (Tip diameter) (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Available | Quote | 10 | For straight | No | 3 | 10 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 3 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 4 | 10 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 4 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 4 | 25 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 5 | 10 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 6 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 6 | 20 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 6 | 25 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 6 | 30 | - | - | - | |
| 1 | Available | Quote | 10 | For straight | No | 8 | 25 | - | - | - | |
| 1 | Quote | 10 | For straight, tapered | Yes | 2 | 15 ～ 25 | 2.5 ～ 3.5 | - | 2.5 ～ 4 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 2 | - | 2.5 ～ 3.5 | 15.1 ～ 24.9 | 2.5 ～ 4 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 3 | 10 ～ 25 | 3.5 ～ 4.5 | - | 3.5 ～ 5 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 3 | - | 3.5 ～ 4.5 | 10.1 ～ 24.9 | 3.5 ～ 5 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 4 | 15 ～ 25 | 4.5 ～ 6.5 | - | 4.5 ～ 7 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 4 | - | 4.5 ～ 6.5 | 15.1 ～ 24.9 | 4.5 ～ 7 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 5 | 15 ～ 25 | 5.5 ～ 6.5 | - | 5.5 ～ 7 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 5 | - | 5.5 ～ 6.5 | 15.1 ～ 24.9 | 5.5 ～ 7 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 6 | 15 ～ 30 | 6.5 ～ 8.5 | - | 6.5 ～ 9 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 6 | - | 6.5 ～ 8.5 | 15.1 ～ 29.9 | 6.5 ～ 9 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 8 | 15 ～ 30 | 8.5 ～ 11.5 | - | 8.5 ～ 12 | ||
| 1 | Quote | 10 | For straight, tapered | Yes | 8 | - | 8.5 ～ 11.5 | 15.1 ～ 29.9 | 8.5 ～ 12 | ||
| 1 | Available | Quote | 10 | For tapered | No | 4 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 4 | 20 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 4 | 25 | - | - | - | |
| 1 | Quote | 10 | For tapered | Yes | 4 | - | - | - | - | ||
| 1 | Available | Quote | 10 | For tapered | No | 5 | 10 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 5 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 5 | 20 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 5 | 25 | - | - | - | |
| 1 | Quote | 10 | For tapered | Yes | 5 | - | - | - | - | ||
| 1 | Available | Quote | 10 | For tapered | No | 6 | 15 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 6 | 20 | - | - | - | |
| 1 | Available | Quote | 10 | For tapered | No | 6 | 25 | - | - | - | |
| 1 | Quote | 10 | For tapered | Yes | 6 | 15 ～ 25 | - | - | - | ||
| 1 | Quote | 10 | For tapered | Yes | 8 | 15 ～ 25 | - | - | - | ||
| 1 | Quote | 10 | For tapered | Yes | 10 | 25 | - | - | - |
