Shaft holders / high block form / one-piece / long version
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
D dimensions 30 ~ 40 come with 2 screws.
| Type | Material | Surface Treatment | Accessory |
| SHSCN | EN 1.1191 Equiv. | Black Oxide | Hex Socket Set Screw 1 pc. |
| SHBMN | Electroless Nickel Plating | Hex Socket Set Screw 1 pc. (Stainless Steel) |
Specifications
| Part Number | - | H | |
| SHBM16 SHSCN20 | - - | 25 30 |
| Part Number | H Selection | L | H1 | T | L1 | Set Screw M | M1 | Unit Price | |||||||
| Type | D | SHSCN | SHBMN | ||||||||||||
| SHSCN SHBMN | 10 | 20 | 25 | 30 | 22 | H+10 | 18 | 12 | M6 | M6 | |||||
| 12 | 20 | 25 | 30 | H+11 | |||||||||||
| 16 | 25 | 30 | 40 | 25 | H+15 | 20 | 14 | ||||||||
| 20 | 25 | 30 | 40 | 50 | 32 | H+18 | 25 | 18 | M8 | M8 | |||||
| 25 | 30 | 40 | 50 | 38 | H+20 | 30 | 24 | ||||||||
| 30 | 30 | 40 | 50 | 60 | 50 | H+23 | 35 | 32 | |||||||
| 35 | 40 | 50 | 60 | H+25 | |||||||||||
| 40 | 40 | 50 | 60 | H+30 | 40 | ||||||||||
Alterations
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| SHBMN10-20 |
| SHBMN10-25 |
| SHBMN10-30 |
| SHBMN12-[20,25,30] |
| SHBMN16-[25,30,40] |
| SHBMN20-[25,30,40,50] |
| SHBMN25-[30,40,50] |
| SHBMN30-[30,40,50,60] |
| SHBMN35-[40,50,60] |
| SHBMN40-[40,50,60] |
| SHSCN10-20 |
| SHSCN10-25 |
| SHSCN10-30 |
| SHSCN12-[20,25,30] |
| SHSCN16-[25,30,40] |
| SHSCN20-[25,30,40,50] |
| SHSCN25-[30,40,50] |
| SHSCN30-[30,40,50,60] |
| SHSCN35-[40,50,60] |
| SHSCN40-[40,50,60] |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Hole Dia. D (mm) | Surface Treatment | Height H (mm) | |
|---|---|---|---|---|---|---|---|---|
22.99 € | 1 | Available | 8 Days | 10 | 10 | Electroless Nickel Plating | 20 | |
22.99 € | 1 | Available | 8 Days | 10 | 10 | Electroless Nickel Plating | 25 | |
22.99 € | 1 | Available | 8 Days | 10 | 10 | Electroless Nickel Plating | 30 | |
- | 1 | 8 Days | 10 | 12 | Electroless Nickel Plating | 20 ～ 30 | ||
- | 1 | 8 Days | 10 | 16 | Electroless Nickel Plating | 25 ～ 40 | ||
- | 1 | 8 Days | 10 | 20 | Electroless Nickel Plating | 25 ～ 50 | ||
- | 1 | 8 Days | 10 | 25 | Electroless Nickel Plating | 30 ～ 50 | ||
- | 1 | 8 Days | 10 | 30 | Electroless Nickel Plating | 30 ～ 60 | ||
- | 1 | 8 Days | 10 | 35 | Electroless Nickel Plating | 40 ～ 60 | ||
- | 1 | 8 Days | 10 | 40 | Electroless Nickel Plating | 40 ～ 60 | ||
19.05 € | 1 | Available | 8 Days | 10 | 10 | Black Oxide | 20 | |
19.05 € | 1 | Available | 8 Days | 10 | 10 | Black Oxide | 25 | |
19.05 € | 1 | Available | 8 Days | 10 | 10 | Black Oxide | 30 | |
- | 1 | 8 Days | 10 | 12 | Black Oxide | 20 ～ 30 | ||
- | 1 | 8 Days | 10 | 16 | Black Oxide | 25 ～ 40 | ||
- | 1 | 8 Days | 10 | 20 | Black Oxide | 25 ～ 50 | ||
- | 1 | 8 Days | 10 | 25 | Black Oxide | 30 ～ 50 | ||
- | 1 | 8 Days | 10 | 30 | Black Oxide | 30 ～ 60 | ||
- | 1 | 8 Days | 10 | 35 | Black Oxide | 40 ～ 60 | ||
- | 1 | 8 Days | 10 | 40 | Black Oxide | 40 ～ 60 |
Loading...
Basic information
| Shape | Block Shape | Shaft Mounting Method | Set Screw | Material | EN 1.1191 Equiv. |
|---|---|---|---|---|---|
| Type | Machined Products | Block shape mounting method | Bottom Tapped Hole | Thickness | Thick Wall |
| Dowel Holes | Not Provided | Clamping Lever | Not Provided |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
Complementary Products
-
Plain bearing bushes / flange selectable / with housing, number of bushes selectable / seal selectable
MISUMI Standard Price : 13.33 € Shipping Days: Same day
-
Set collars / stainless steel, steel / wedge clamping / double cross hole, cross thread
MISUMI Standard Price : 5.44 € Shipping Days: Same day
-
Linear ball bearings / wide block shape / aluminium / anodised / single double bush
MISUMI Standard Price : 16.58 € Shipping Days: Same day
-
Linear ball bearings / stainless steel, steel / chrome-plated, nickel-plated / double ring groove
MISUMI Standard Price : 3.35 € Shipping Days: Same day
MISUMI Unit еxample related to this product
