Indexing Plungers / Plate Mount
- Volume Discount
[Features] It can be used in places where there is no space for a knob.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Type | Knob | Main Body | Pin | Spring | |||
| Material | Material | Surface Treatment | Material | Hardness | Surface Treatment | Material | |
| PXSP PXSPL | Polyacetal | EN 1.1191 Equiv. | Black Oxide | EN 1.1191 Equiv. | 50~60HRC (Carburized) | Black Oxide | EN 1.4568 Equiv. |
Specifications
| Part Number |
| PXSP6 |
| Part Number | Load (N) | Unit Price | ||
| Type | B | min. | max. | |
| PXSP PXSPL | 6 | 0.1 | 1.9 | |
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
Loading...
Example of Use
Basic information
| Type | Standard Type | Locking Mechanism | Cam Type | Mounting Method | Flange |
|---|---|---|---|---|---|
| Overall Length | Short | Body Material | EN 1.1191 Equiv. | Pin Material | EN 1.1191 Equiv. |
| Stroke (S)(mm) | 6 | Knob | Provided | Main Body Surface Treatment | Black Oxide |
| Pin Surface Treatment | Black Oxide | Tip Heat Treatment | Hardened | Tip Outer Dia. B(Ø) | 6 |
| Length L(mm) | 48 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
