Shock Absorbers / Compact
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Material: Free Cutting Steel
Surface Treatment: Electroless Nickel Plating
Specifications
| Part Number |
| MAMS2006 MAMKS2508 |
| Part Number | Thread Dia. | Stroke | Max. Absorbed Energy (E’) | Max. Equiv. Mass (me’)(kg) | Piston Rod Return Force (N) | Max. Drag Value (N) | (L1) | (L2) | d1 | f | B (Wrench Flats) | T | Unit Price | Volume Discount Rate | ||
| Type | No. | MxP | S | per Impact (J) | per Minute (J) | |||||||||||
| 1 ~ 4 pc(s). | 5 ~ 10 pcs. | |||||||||||||||
| MAMS | 1406 | M14x1.5 | 6 | 3.5 | 100 | 80 | 15 | 2,000 | 41 | 8 | 4 | 2 | 19.6(17) | 6 | ||
| 1606 | M16x1.5 | 4.8 | 130 | 120 | 20 | 2,700 | 5 | 20(19) | ||||||||
| 2006 | M20x1.5 | 7.8 | 200 | 60 | 16.7 | 3,920 | 43 | 6 | 6 | 1.5 | 27.7(24) | 8 | ||||
| 2506 | M25x1.5 | 11.7 | 300 | 90 | 19.6 | 5,880 | 8 | 37(32) | 10 | |||||||
| 2706 | M27x1.5 | 15.6 | 350 | 120 | 22.6 | 7,840 | ||||||||||
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| MAMS1406 |
| MAMS1606 |
| MAMS2006 |
| MAMS2506 |
| MAMS2706 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Mounting Screw Nominal (M) | Max. Absorbed Energy (J) | Equivalent Mass (kgf) | Max. Resisting Force Value (N) | Piston Rod Return Force (N) | Max. Absorbed Energy (per Minute) (J/min) | Thread Size M | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
78.25 € | 1 | Available | 5 Days | 10 | M14 | 3.5 | 80 | 2000 | 15 | 100 | M14X1.5 | |
83.14 € | 1 | Available | 5 Days | 10 | M16 | 4.8 | 120 | 2700 | 20 | 130 | M16X1.5 | |
85.59 € | 1 | Available | 5 Days | 10 | M20 | 7.8 | 60 | 3920 | 16.7 | 200 | M20X1.5 | |
97.81 € | 1 | Available | 5 Days | 10 | M25 | 11.7 | 90 | 5880 | 19.6 | 300 | M25X1.0 | |
110.05 € | 1 | Available | 5 Days | 10 | M27 | 15.6 | 120 | 7840 | 22.6 | 350 | M27X1.5 |
Loading...
Basic information
| Main Body, Related Components | Main Body | Structure | Compact Adjustable | Stroke(mm) | 6 |
|---|---|---|---|---|---|
| Orifice Type | Tapered orifice | Usage Environment | Standard | Main Body Material | JIS-SUM Free Cutting Steel |
| Max. Collision Velocity(m/s) | 1 | Min. Collision Velocity(m/s) | 0.3 | Max. Operating Cycle(cycle/min) | 60 |
| Operating Temperature Range(°C) | -5::70 |
Configure
Basic Attributes
-
Max. Absorbed Energy(J)
-
Equivalent Mass(kgf)
-
Max. Resisting Force Value(N)
-
Piston Rod Return Force(N)
-
Max. Absorbed Energy (per Minute)(J/min)
-
Thread Size M
-
Type
- MAMS
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
