Stainless Steel Grooved Bearing Convex
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Material: EN 1.4125 Equiv.
Specifications
| Part Number | - | D |
| SZV3 SZU3 | - - | 12 12 |
| Part Number | D | B | GD | GR (Groove Width) | C Chamfer | R (Corner R) | Basic Load Rating | Relative Dimensions | Mass (g) (Reference) | Unit Price | |||
| Type | d | Cr (Dynamic) N | Co (Static) N | Ds (min) | dh (max) | ||||||||
| SZG | 3 | 12 | 4 | 10 | 2 | (0.25) | 0.25 | 542 | 186 | 4.5 | 7.5 | 1.3 | |
| 3 | 14 | 12 | 1.8 | ||||||||||
| 4 | 12 | 10 | 5.5 | 1.2 | |||||||||
| 4 | 14 | 12 | 1.8 | ||||||||||
| 6 | 16 | 14 | 650 | 235 | 7.5 | 10 | 2.1 | ||||||
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| SZG3-12 |
| SZG3-14 |
| SZG4-12 |
| SZG4-14 |
| SZG6-16 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | I.D. d (φ) | O.D. D (φ) | Basic Load Rating Cr (Dynamic) (N) | Basic Load Rating Cor (Static) (N) | |
|---|---|---|---|---|---|---|---|---|---|
9.54 € | 1 | Available | 5 Days | 10 | 3 | 12 | 542 | 186 | |
9.54 € | 1 | Available | 5 Days | 10 | 3 | 14 | 542 | 186 | |
10.03 € | 1 | Available |
Same day
Stock | 10 | 4 | 12 | 542 | 186 | |
10.03 € | 1 | Available | 5 Days | 10 | 4 | 14 | 542 | 186 | |
10.64 € | 1 | Available | 5 Days | 10 | 6 | 16 | 650 | 235 |
Loading...
More Information
Basic information
| Bearing Ring Shape | Ball | Materials of Inner and Outer Ring | EN 1.4125 Equiv. | Shield material and shape | Double Shielded |
|---|---|---|---|---|---|
| Outer Ring Type | Grooved | Accuracy (JIS) | Class 0 | Width B (or T)(mm) | 4 |
| Specifications/Environment | Standard | Number of Bearing Ring Rows | Single Track | Size Standard | Metric Series |
| Rolling Element Material | EN 1.4125 Equiv. | Seal Part Structure | Double Shielded |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
