Battery Contact Spring Plates
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| BS501 |
| BS502 |
| BS503 |
| BS504 |
| BS505 |
| BS506 |
| BS507 |
| BS509 |
| BS510 |
| BS511 |
| BS512 |
| BS551 |
| BS552 |
| BS557 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Contact Pole | Compatible Battery Size | Material | Shape | |
|---|---|---|---|---|---|---|---|---|---|
3.03 € | 1 | Available |
Same day
Stock | 10 | For Both Terminals | For Size AA Battery | EN CW507L Equiv. Ni plating | Left Positive Terminal/Right Negative Terminal | |
2.07 € | 10 | Available | 9 Days | 10 | For Both Terminals | For Size AA Battery | EN CW507L Equiv. Ni plating | Right Negative Terminal/Left Positive Terminal | |
3.03 € | 1 | Available |
Same day
Stock | 10 | For Both Terminals | For Size AA Battery | EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating | Left Positive Terminal/Right Negative TerminalCoil Spring Assembly Type | |
4.05 € | 1 | Available | 5 Days | 10 | For Both Terminals | For Size AA Battery | EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating | Left Negative Terminal/Right Positive TerminalCoil Spring Assembly Type | |
1.42 € | 1 | Available |
Same day
Stock | 10 | For Positive Terminal | For Size AA Battery | EN CW507L Equiv. Ni plating | Type with Claw | |
2.07 € | 10 | Available | 5 Days | 10 | For Positive Terminal | For Size AA Battery | EN CW507L Equiv. 1/2 Material with Ni-Plating | Flat Type | |
1.51 € | 1 | Available |
Same day
Stock | 10 | For Negative Terminal | For Size AA Battery | EN CW507L Equiv. Ni plating | Flat-Spring Type | |
1.64 € | 1 | Available |
Same day
Stock | 10 | For Negative Terminal | For Size AA Battery | EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating | Coil Spring Assembly Type | |
4.05 € | 5 | Available | 9 Days | 10 | For Both Terminals | For Size AAA Battery | EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating | - | |
1.42 € | 1 | Available |
Same day
Stock | 10 | For Positive Terminal | For Size AAA Battery | EN CW507L Equiv. 1/2 Material with Ni-Plating | - | |
2.04 € | 1 | Available |
Same day
Stock | 10 | For Negative Terminal | For Size AAA Battery | EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating | - | |
2.07 € | 10 | Available | 9 Days | 10 | For Both Terminals | For Size AA Battery | EN CW459K Equiv. Ni plating | Left Positive Terminal/Right Negative Terminal | |
2.07 € | 10 | Available | 5 Days | 10 | For Both Terminals | For Size AA Battery | EN CW459K Equiv. Ni plating | Right Negative Terminal/Left Positive Terminal | |
2.04 € | 1 | Available |
Same day
Stock | 10 | For Negative Terminal | For Size AA Battery | EN CW459K Equiv. Ni plating | Flat-Spring Type |
Loading...
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Contact Pole
- For Both Terminals
- For Negative Terminal
- For Positive Terminal
-
Compatible Battery Size
- For Size AA Battery
- For Size AAA Battery
-
Material
- EN CW459K Equiv. Ni plating
- EN CW507L Equiv. Ni plating
- EN CW507L Equiv., JIS-SWC (spring steel) , Ni Plating
- EN CW507L Equiv. 1/2 Material with Ni-Plating
-
Shape
- Coil Spring Assembly Type
- Flat-Spring Type
- Flat Type
- Left Negative Terminal/Right Positive TerminalCoil Spring Assembly Type
- Left Positive Terminal/Right Negative Terminal
- Left Positive Terminal/Right Negative TerminalCoil Spring Assembly Type
- Right Negative Terminal/Left Positive Terminal
- Type with Claw
-
Type
- BS-F
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
- 9 Days or Less
Optional Attributes
- The price of this product varies (downward) depending on quantity. For details, confirm with "price check".
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
