Single Clevis Knuckle Joint for CMK2, CMA2, CKV2, JSK2, JSM2, HCA
[Features]
· CKD, CMK2, CMA2, CKV2, JSK2, JSM2, HCA single clevis knuckle usage
· CKD, CMK2, CMA2, CKV2, JSK2, JSM2, HCA single clevis knuckle usage
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
M1-I-20
- Product data
- CAD data not available
Basic information
| Type of Support | Single Clevis Knuckle Joints | Mounting Method | Female Thread | Thread Size M(mm) | M8 |
|---|---|---|---|---|---|
| Thread Pitch(mm) | 1 | Material | Steel | Accessories Included | Without Attachment |
| Applicable Cylinder Series | CMK2, CMA2, CKV2, JSK2, JSM2, HCA | Applicable Tube I.D. (mm) | 20 |
This page is Single Clevis Knuckle Joint for CMK2, CMA2, CKV2, JSK2, JSM2, HCA, part number M1-I-20.
You can find the detail information about specifications and dimensions on part number M1-I-20.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
