SSD Single Clevis Knuckle Joint
- Volume Discount
Single clevis knuckle joint for cylinder SSD.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| SSD-I-16 |
| SSD-I-20 |
| SSD-I-32 |
| SSD-I-40 |
| SSD-I-50 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Thread Size M (mm) | Thread Pitch (mm) | Applicable Tube I.D. (mm) | |
|---|---|---|---|---|---|---|---|
6.49 € | 1 | 6 Days | M6 | - | 16 | ||
14.02 € | 1 | 6 Days | M8 | - | 20 | ||
14.33 € | 1 | 6 Days | M14 | 1.5 | 32 | ||
17.86 € | 1 | 6 Days | M14 | 1.5 | 40 | ||
17.72 € | 1 | 6 Days | M18 | 1.5 | 50 |
Loading...
Basic information
| Type of Support | Single Clevis Knuckle Joints | Mounting Method | Female Thread | Accessories Included | Without Attachment |
|---|---|---|---|---|---|
| Applicable Cylinder Series | SSD |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
