With Open Chuck Floating, Panel Mount Type Chuck Direction Parallel

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
CHM08BC02H
CHM08BC03C
CHM08BC03H
CHM08BC04H
CHM08BC05C
CHM08BC06H
CHM08BC07C
CHM08BC08H
CHM11BC06C
CHM11BC06H
CHM11BC08C
CHM11BC08H
CHM11BC10C
CHM11BC10H
CHM11BC12C
CHM11BC12H
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Gripping Force (when 0.5Mpa at opening)
(N)
Gripping Force (when 0.5Mpa at closing)
(N)
Gripper Finger Shape Workpiece Groove Width
(mm)
Work dimensions hole diameter
(mm)

112.92 €

1 11 Days 0.080.08For Circular Hole-shaped Workpiece-2–3

112.92 €

1 11 Days 0.080.08For Groove-shaped Workpiece3–5-

112.92 €

1 11 Days 0.080.08For Circular Hole-shaped Workpiece-3–4

112.92 €

1 11 Days 0.080.08For Circular Hole-shaped Workpiece-4–6

112.92 €

1 11 Days 0.080.08For Groove-shaped Workpiece5–7-

112.92 €

1 11 Days 0.080.08For Circular Hole-shaped Workpiece-6–8

112.92 €

1 11 Days 0.080.08For Groove-shaped Workpiece7–9-

112.92 €

1 11 Days 0.080.08For Circular Hole-shaped Workpiece-8–10

96.17 €

1 11 Days 0.200.20For Groove-shaped Workpiece6–8-

96.17 €

1 11 Days 0.200.20For Circular Hole-shaped Workpiece-6–8

96.17 €

1 11 Days 0.200.20For Groove-shaped Workpiece8–10-

96.17 €

1 11 Days 0.200.20For Circular Hole-shaped Workpiece-8–10

96.18 €

1 11 Days 0.200.20For Groove-shaped Workpiece10–12-

96.18 €

1 11 Days 0.200.20For Circular Hole-shaped Workpiece-10–12

96.18 €

1 11 Days 0.200.20For Groove-shaped Workpiece12–14-

96.18 €

1 11 Days 0.200.20For Circular Hole-shaped Workpiece-12–14

Loading...

  1. 1

Basic information

Type Main Body How to Grip Swing Type of Opening Number of Fingers 2 pcs.
Main Body Shape Cylindrical Operation Method Single Acting Type (Normally Close) Environment, Applications Standard
Additional Function NA Stroke Adjustment Mechanism NA Operating Pressure Range(MPa) 0.2::0.7
Mounting Holder Shape Panel Mount Type with Floating Chuck Direction Parallel
