Tube Fitting for General Piping - Mini Type with Different Diameters Union Straight

Tube Fitting for General Piping - Mini Type with Different Diameters Union Straight
  • Volume Discount
[Features]
· Ultra-small one-touch fitting for general pneumatic pipes.
· Reduced size with a volume ratio of 40% over the standard type.
· Elliptical release ring allows easy tube release.
· The 1.8 mm diameter type is an industry-first minimum one-touch type.
· Optimum for piping of small actuators, etc.
· Light gray types and clean room packaged types optionally available.
· Clean room packaging specifications define the use of fluorinated grease.
· After purification with clean air, the item is packaged in an ISO Class 6-equivalent clean room.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
PG1/4-1/8M
PG1/4-5/32M
PG3-180M
PG4-1/8M
PG4-3M
PG4-3MW
PG4-180M
PG4-180MW
PG6-1/8M
PG6-3M
PG6-4M
PG6-4MW
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSCompatible Tube Outer Diameter 1
(mm)
Compatible Tube Outer Diameter 2
(mm)
Release Ring Color Resin Body Color

3.17 €

10 12 Days -6.353.2BlackBlack

2.79 €

10 17 Days -6.353.97BlackBlack

2.38 €

10 5 Days 1031.8BlackBlack

2.83 €

10 Available 5 Days -43.2BlackBlack

2.61 €

10 5 Days 1043BlackBlack

2.75 €

10 11 Days -43Light GrayLight Gray

2.61 €

10 12 Days -41.8BlackBlack

2.61 €

10 11 Days -41.8Light GrayLight Gray

2.89 €

10 12 Days -63.2BlackBlack

3.00 €

1 Available Same day

Stock

-63BlackBlack

3.62 €

1 Same day

Stock

1064BlackBlack

2.89 €

10 11 Days -64Light GrayLight Gray

Loading...

  1. 1

Basic information

Type Single-Action Coupling Fitting Type Union with different diameters Applicable Fluid Air
Application Standard/Mini Union: Unequal Diameter Different Diameter Union Straight Operating Temperature(°C) 0::60
Package Specifications Regular Packaging Specifications
