Saddle Band Thickness Saddle Bolt Hole (Electro Zinc Plated / Stainless Steel)
- Volume Discount
[Features]
· Saddle band for SGP pipe.
· Bolt-fixture type with large holes.
· Can be installed on frames.
· Electrogalvanized finish.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Main fit tube(or application tube)outside diameter (mm) | Applicable Pipe Type | Material | Surface Treatment | The size of diameter of steel pipe (A) | Nominal Diameter (B) | Compatible Pipe Outer Diameter (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
3.93 € | 1 | 8 Days | 20～Less than 30 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 15A | 1/2 | 21.7 | ||
1.49 € | 1 | Available | 6 Days | 20～Less than 30 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 20A | 3/4 | 27.2 | |
1.88 € | 1 | Available |
Same day
Stock | 30～Less than 40 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 25A | 1 | 34 | |
5.10 € | 1 | 6 Days | 40～Less than 50 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 32A | 1 1/4 | 42.7 | ||
2.11 € | 1 | Available |
Same day
Stock | 40～Less than 50 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 40A | 1 1/2 | 48.6 | |
2.38 € | 1 | Available |
Same day
Stock | 60～Less than 70 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 50A | 2 | 60.5 | |
4.54 € | 1 | 6 Days | 70～Less than 80 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 65A | 2 1/2 | 76.3 | ||
2.86 € | 1 | Available |
Same day
Stock | 80～Less than 90 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 80A | 3 | 89.1 | |
7.06 € | 1 | 6 Days | 100～Less than 200 | [Steel Pipe / Coated Steel Pipe] SGP Pipe | Steel | - | 100A | 4 | 114.3 | ||
13.00 € | 1 | 9 Days | 20～Less than 30 | Stainless Steel Pipe | Stainless Steel | NA | 15A | 1/2 | 21.7 | ||
6.07 € | 1 | Available |
Same day
Stock | 20～Less than 30 | Stainless Steel Pipe | Stainless Steel | NA | 20A | 3/4 | 27.2 | |
13.58 € | 1 | 6 Days | 30～Less than 40 | Stainless Steel Pipe | Stainless Steel | NA | 25A | 1 | 34 | ||
7.05 € | 1 | Available |
Same day
Stock | 40～Less than 50 | Stainless Steel Pipe | Stainless Steel | NA | 32A | 1 1/4 | 42.7 | |
8.26 € | 1 | Available |
Same day
Stock | 40～Less than 50 | Stainless Steel Pipe | Stainless Steel | NA | 40A | 1 1/2 | 48.6 | |
8.85 € | 1 | Available |
Same day
Stock | 60～Less than 70 | Stainless Steel Pipe | Stainless Steel | NA | 50A | 2 | 60.5 | |
15.22 € | 1 | 9 Days | 70～Less than 80 | Stainless Steel Pipe | Stainless Steel | NA | 65A | 2 1/2 | 76.3 | ||
15.52 € | 1 | 9 Days | 80～Less than 90 | Stainless Steel Pipe | Stainless Steel | NA | 80A | 3 | 89.1 | ||
19.92 € | 1 | 9 Days | 100～Less than 200 | Stainless Steel Pipe | Stainless Steel | NA | 100A | 4 | 114.3 |
Loading...
Basic information
| Type | Saddle Band | Number Contained In A Packet(piece) | 1 |
|---|
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Main fit tube(or application tube)outside diameter(mm)
-
Applicable Pipe Type
- Steel Pipe / Coated Steel Pipe
- Stainless Steel Pipe
- Steel Pipe / Coated Steel Pipe
-
Material
-
Surface Treatment
- NA
-
The size of diameter of steel pipe (A)
-
Nominal Diameter (B)
-
Compatible Pipe Outer Diameter(mm)
-
Type
- A10432
- A10454
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 8 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
