Welding Pipe Fitting Reducer (Concentric)

Welding Pipe Fitting Reducer (Concentric)

AWAJI MATERIA

AWAJI MATERIA

JIS B 2311, JIS B 2312-compliant steel butt welding pipe fitting.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  6. Next >>
Part Number
FSGP-R-C-1-1/2B-1-1/4B-B
FSGP-R-C-1-1/2B-1-1/4B-W
FSGP-R-C-1-1/2B-1/2B-B
FSGP-R-C-1-1/2B-1/2B-W
FSGP-R-C-1-1/2B-1B-B
FSGP-R-C-1-1/2B-1B-W
FSGP-R-C-1-1/2B-3/4B-B
FSGP-R-C-1-1/2B-3/4B-W
FSGP-R-C-1-1/4B-1/2B-B
FSGP-R-C-1-1/4B-1/2B-W
FSGP-R-C-1-1/4B-1B-B
FSGP-R-C-1-1/4B-1B-W
FSGP-R-C-1-1/4B-3/4B-B
FSGP-R-C-1-1/4B-3/4B-W
FSGP-R-C-1B-1/2B-B
FSGP-R-C-1B-1/2B-W
FSGP-R-C-1B-3/4B-B
FSGP-R-C-1B-3/4B-W
FSGP-R-C-2-1/2B-1-1/2B-B
FSGP-R-C-2-1/2B-1-1/2B-W
FSGP-R-C-2-1/2B-1-1/4B-B
FSGP-R-C-2-1/2B-1-1/4B-W
FSGP-R-C-2-1/2B-1B-B
FSGP-R-C-2-1/2B-1B-W
FSGP-R-C-2-1/2B-2B-B
FSGP-R-C-2-1/2B-2B-W
FSGP-R-C-2B-1-1/2B-B
FSGP-R-C-2B-1-1/2B-W
FSGP-R-C-2B-1-1/4B-B
FSGP-R-C-2B-1-1/4B-W
FSGP-R-C-2B-1B-B
FSGP-R-C-2B-1B-W
FSGP-R-C-2B-3/4B-B
FSGP-R-C-2B-3/4B-W
FSGP-R-C-3/4B-1/2B-B
FSGP-R-C-3/4B-1/2B-W
FSGP-R-C-3B-1-1/2B-B
FSGP-R-C-3B-1-1/2B-W
FSGP-R-C-3B-1-1/4B-B
FSGP-R-C-3B-1-1/4B-W
FSGP-R-C-3B-2-1/2B-B
FSGP-R-C-3B-2-1/2B-W
FSGP-R-C-3B-2B-B
FSGP-R-C-3B-2B-W
FSGP-R-C-4B-1-1/2B-B
FSGP-R-C-4B-1-1/2B-W
FSGP-R-C-4B-2-1/2B-B
FSGP-R-C-4B-2-1/2B-W
FSGP-R-C-4B-2B-B
FSGP-R-C-4B-2B-W
FSGP-R-C-4B-3B-B
FSGP-R-C-4B-3B-W
FSGP-R-C-5B-2-1/2B-B
FSGP-R-C-5B-2-1/2B-W
FSGP-R-C-5B-2B-B
FSGP-R-C-5B-2B-W
FSGP-R-C-5B-3B-B
FSGP-R-C-5B-3B-W
FSGP-R-C-5B-4B-B
FSGP-R-C-5B-4B-W
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Material Surface Treatment Nominal Thickness Nominal Dia. Nominal Dia. (2nd Fitting) Outer Diameter D1
(φ mm) 		Outer Diameter D2
(φ mm) 		Distance to the end face from the end face
(mm)

7.38 €

1 8 Days [Steel] FSGPNA-1 1/2B1 1/4B48.642.763.5

12.45 €

1 8 Days [Steel] FSGPZinc Plating-1 1/2B1 1/4B48.642.763.5

13.35 €

1 8 Days [Steel] FSGPNA-1 1/2B1/2B48.621.763.5

25.02 €

1 10 Days [Steel] FSGPZinc Plating-1 1/2B1/2B48.621.763.5

7.38 €

1 8 Days [Steel] FSGPNA-1 1/2B1B48.63463.5

12.45 €

1 8 Days [Steel] FSGPZinc Plating-1 1/2B1B48.63463.5

11.16 €

1 8 Days [Steel] FSGPNA-1 1/2B3/4B48.627.263.5

20.77 €

1 8 Days [Steel] FSGPZinc Plating-1 1/2B3/4B48.627.263.5

11.16 €

1 8 Days [Steel] FSGPNA-1 1/4B1/2B42.721.750.8

20.76 €

1 10 Days [Steel] FSGPZinc Plating-1 1/4B1/2B42.721.750.8

7.38 €

1 8 Days [Steel] FSGPNA-1 1/4B1B42.73450.8

12.45 €

1 8 Days [Steel] FSGPZinc Plating-1 1/4B1B42.73450.8

7.38 €

1 7 Days [Steel] FSGPNA-1 1/4B3/4B42.727.250.8

12.45 €

1 8 Days [Steel] FSGPZinc Plating-1 1/4B3/4B42.727.250.8

7.22 €

1 7 Days [Steel] FSGPNA-1B1/2B3421.750.8

12.23 €

1 7 Days [Steel] FSGPZinc Plating-1B1/2B3421.750.8

7.22 €

1 8 Days [Steel] FSGPNA-1B3/4B3427.250.8

12.23 €

1 8 Days [Steel] FSGPZinc Plating-1B3/4B3427.250.8

11.03 €

1 8 Days [Steel] FSGPNA-2 1/2B1 1/2B76.348.688.9

20.53 €

1 7 Days [Steel] FSGPZinc Plating-2 1/2B1 1/2B76.348.688.9

16.67 €

1 8 Days [Steel] FSGPNA-2 1/2B1 1/4B76.342.788.9

32.65 €

1 7 Days [Steel] FSGPZinc Plating-2 1/2B1 1/4B76.342.788.9

20.03 €

1 8 Days [Steel] FSGPNA-2 1/2B1B76.33488.9

39.20 €

1 8 Days [Steel] FSGPZinc Plating-2 1/2B1B76.33488.9

11.03 €

1 7 Days [Steel] FSGPNA-2 1/2B2B76.360.588.9

20.53 €

1 7 Days [Steel] FSGPZinc Plating-2 1/2B2B76.360.588.9

7.86 €

1 8 Days [Steel] FSGPNA-2B1 1/2B60.548.676.2

14.94 €

1 8 Days [Steel] FSGPZinc Plating-2B1 1/2B60.548.676.2

7.86 €

1 8 Days [Steel] FSGPNA-2B1 1/4B60.542.776.2

14.94 €

1 8 Days [Steel] FSGPZinc Plating-2B1 1/4B60.542.776.2

11.86 €

1 8 Days [Steel] FSGPNA-2B1B60.53476.2

23.37 €

1 8 Days [Steel] FSGPZinc Plating-2B1B60.53476.2

14.36 €

1 8 Days [Steel] FSGPNA-2B3/4B60.527.276.2

28.09 €

1 8 Days [Steel] FSGPZinc Plating-2B3/4B60.527.276.2

7.22 €

1 8 Days [Steel] FSGPNA-3/4B1/2B27.221.738.1

12.23 €

1 8 Days [Steel] FSGPZinc Plating-3/4B1/2B27.221.738.1

19.47 €

1 8 Days [Steel] FSGPNA-3B1 1/2B89.148.688.9

39.48 €

1 8 Days [Steel] FSGPZinc Plating-3B1 1/2B89.148.688.9

23.30 €

1 8 Days [Steel] FSGPNA-3B1 1/4B89.142.788.9

47.37 €

1 8 Days [Steel] FSGPZinc Plating-3B1 1/4B89.142.788.9

12.93 €

1 8 Days [Steel] FSGPNA-3B2 1/2B89.176.388.9

24.74 €

1 7 Days [Steel] FSGPZinc Plating-3B2 1/2B89.176.388.9

12.93 €

1 7 Days [Steel] FSGPNA-3B2B89.160.588.9

24.74 €

1 7 Days [Steel] FSGPZinc Plating-3B2B89.160.588.9

34.77 €

1 8 Days [Steel] FSGPNA-4B1 1/2B114.348.6101.6

70.73 €

1 8 Days [Steel] FSGPZinc Plating-4B1 1/2B114.348.6101.6

28.85 €

1 8 Days [Steel] FSGPNA-4B2 1/2B114.376.3101.6

58.99 €

1 7 Days [Steel] FSGPZinc Plating-4B2 1/2B114.376.3101.6

28.85 €

1 8 Days [Steel] FSGPNA-4B2B114.360.5101.6

58.99 €

1 8 Days [Steel] FSGPZinc Plating-4B2B114.360.5101.6

19.47 €

1 8 Days [Steel] FSGPNA-4B3B114.389.1101.6

37.10 €

1 7 Days [Steel] FSGPZinc Plating-4B3B114.389.1101.6

42.95 €

1 8 Days [Steel] FSGPNA-5B2 1/2B139.876.3127

88.02 €

1 8 Days [Steel] FSGPZinc Plating-5B2 1/2B139.876.3127

51.45 €

1 8 Days [Steel] FSGPNA-5B2B139.860.5127

84.44 €

1 8 Days [Steel] FSGPZinc Plating-5B2B139.860.5127

42.95 €

1 8 Days [Steel] FSGPNA-5B3B139.889.1127

88.02 €

1 8 Days [Steel] FSGPZinc Plating-5B3B139.889.1127

30.84 €

1 8 Days [Steel] FSGPNA-5B4B139.8114.3127

59.54 €

1 8 Days [Steel] FSGPZinc Plating-5B4B139.8114.3127

Loading...

  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  6. Next >>

Basic information

Type Butt Welding Type Fitting Shape Reducer Applicable Fluid Water / Air / Vapor / Gas / Oil
Specifications Concentric

Configure

Clear all

271Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Material

    • Steel
      • EN 1.0305 Equiv.
      • FSGP

    Clear

  • Surface Treatment

    • NA
    • Zinc Plating

    Clear

  • Nominal Thickness

    • SCH40
    • SCH80

    Clear

  • Nominal Dia.

    • 3/4B
    • 1B
    • 1 1/4B
    • 1 1/2B
    • 2B
    • 2 1/2B
    • 3B
    • 4B
    • 5B
    • 6B
    • 8B
    • 10B
    • 12B
    • 14B

    Clear

  • Nominal Dia. (2nd Fitting)

    • 1/2B
    • 3/4B
    • 1B
    • 1 1/4B
    • 1 1/2B
    • 2B
    • 2 1/2B
    • 3 1/2B
    • 3B
    • 4B
    • 5B
    • 6B
    • 8B
    • 10B
    • 12B

    Clear

  • Outer Diameter D1(φ mm)

    • 27.2
    • 34
    • 42.7
    • 48.6
    • 60.5
    • 76.3
    • 89.1
    • 114.3
    • 139.8
    • 165.2
    • 216.3
    • 267.4
    • 318.5
    • 355.6

    Clear

  • Outer Diameter D2(φ mm)

    • 21.7
    • 27.2
    • 34
    • 42.7
    • 48.6
    • 60.5
    • 76.3
    • 89.1
    • 101.6
    • 114.3
    • 139.8
    • 165.2
    • 216.3
    • 267.4
    • 318.5

    Clear

  • Distance to the end face from the end face(mm)

    • 38.1
    • 50.8
    • 63.5
    • 76.2
    • 88.9
    • 101.6
    • 127
    • 139.7
    • 152.4
    • 177.8
    • 203.2
    • 330.2

    Clear

  • Type

    • FSGP
    • PT370

    Clear
