RR Type MC Nylon Wheel for Heavy Loads
A wheel made from MC nylon that features excellent abrasion-resistance and oil-resistance. Can withstand heavy loads.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| RR-50 |
| RR-65 |
| RR-75 |
| RR-100 |
| TRR-65 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Wheel O.D. (mm) | Wheel Width (mm) | Hole Diameter (mm) | Hub Width (mm) | |
|---|---|---|---|---|---|---|---|---|
33.08 € | 1 | 9 Days | 50 | 27 | 10 | 29 | ||
40.45 € | 1 | 9 Days | 65 | 34 | 12 | 39 | ||
43.92 € | 1 | 9 Days | 75 | 36 | 12 | 39 | ||
56.69 € | 1 | 9 Days | 100 | 45 | 12 | 56 | ||
34.92 € | 1 | 14 Days | 65 | 25 | 12 | 29 |
Loading...
Basic information
| Wheel Type | Integrated | Wheel Material | Nylon | Bearing | Available |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
