Mold Spring SM (Medium Load)
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Max. Load (Secified Range) (N) | Customer-Specified Length (mm) | Outer Diameter (mm) | Internal Diameter (mm) | Spring Constant (N/mm) | Maximum Load Capacity | Spring Constant (kgf/mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
0.78 € | 1 | 6 Days | 107.01 to 150.00 | 10 | 8 | 4 | 42.532 | 11 | 4.34 | ||
0.78 € | 1 | 6 Days | 107.01 to 150.00 | 15 | 8 | 4 | 28.322 | 11 | 2.89 | ||
0.87 € | 1 | 6 Days | 107.01 to 150.00 | 20 | 8 | 4 | 21.266 | 11 | 2.17 | ||
0.87 € | 1 | 6 Days | 107.01 to 150.00 | 25 | 8 | 4 | 17.052 | 11 | 1.74 | ||
0.98 € | 1 | 6 Days | 107.01 to 150.00 | 30 | 8 | 4 | 14.21 | 11 | 1.45 | ||
1.03 € | 1 | 6 Days | 107.01 to 150.00 | 35 | 8 | 4 | 12.152 | 11 | 1.24 | ||
1.07 € | 1 | 6 Days | 107.01 to 150.00 | 40 | 8 | 4 | 10.682 | 11 | 1.09 | ||
1.29 € | 1 | 6 Days | 107.01 to 150.00 | 45 | 8 | 4 | 9.506 | 11 | 0.97 | ||
1.49 € | 1 | Available | 6 Days | 107.01 to 150.00 | 50 | 8 | 4 | 8.526 | 11 | 0.87 | |
1.70 € | 1 | Available | 6 Days | 107.01 to 150.00 | 55 | 8 | 4 | 7.742 | 11 | 0.79 | |
1.85 € | 1 | Available | 6 Days | 107.01 to 150.00 | 60 | 8 | 4 | 7.056 | 11 | 0.72 | |
2.05 € | 1 | Available | 6 Days | 107.01 to 150.00 | 65 | 8 | 4 | 6.566 | 11 | 0.67 | |
2.21 € | 1 | Available | 6 Days | 107.01 to 150.00 | 70 | 8 | 4 | 6.076 | 11 | 0.62 | |
2.41 € | 1 | Available | 6 Days | 107.01 to 150.00 | 75 | 8 | 4 | 5.684 | 11 | 0.58 | |
2.63 € | 1 | Available | 6 Days | 107.01 to 150.00 | 80 | 8 | 4 | 5.292 | 11 | 0.54 | |
2.88 € | 1 | Available | 6 Days | 107.01 to 150.00 | 90 | 8 | 4 | 4.704 | 11 | 0.48 | |
0.78 € | 1 | 6 Days | 150.01 to 230.00 | 15 | 10 | 5 | 40.082 | 16 | 4.09 | ||
0.78 € | 1 | 6 Days | 150.01 to 230.00 | 20 | 10 | 5 | 30.674 | 16 | 3.13 | ||
0.87 € | 1 | 6 Days | 150.01 to 230.00 | 25 | 10 | 5 | 24.5 | 16 | 2.50 | ||
0.98 € | 1 | 6 Days | 150.01 to 230.00 | 30 | 10 | 5 | 20.384 | 16 | 2.08 | ||
1.03 € | 1 | 6 Days | 150.01 to 230.00 | 35 | 10 | 5 | 17.444 | 16 | 1.78 | ||
1.07 € | 1 | 6 Days | 150.01 to 230.00 | 40 | 10 | 5 | 15.288 | 16 | 1.56 | ||
1.18 € | 1 | 6 Days | 150.01 to 230.00 | 45 | 10 | 5 | 13.524 | 16 | 1.38 | ||
1.29 € | 1 | 6 Days | 150.01 to 230.00 | 50 | 10 | 5 | 12.25 | 16 | 1.25 | ||
1.29 € | 1 | 6 Days | 150.01 to 230.00 | 55 | 10 | 5 | 11.074 | 16 | 1.13 | ||
1.48 € | 1 | Available |
Same day
Stock | 150.01 to 230.00 | 60 | 10 | 5 | 10.192 | 16 | 1.04 | |
1.49 € | 1 | Available | 6 Days | 150.01 to 230.00 | 65 | 10 | 5 | 9.408 | 16 | 0.96 | |
1.49 € | 1 | Available | 6 Days | 150.01 to 230.00 | 70 | 10 | 5 | 8.722 | 16 | 0.89 | |
1.70 € | 1 | Available | 6 Days | 150.01 to 230.00 | 75 | 10 | 5 | 8.134 | 16 | 0.83 | |
1.85 € | 1 | Available | 6 Days | 150.01 to 230.00 | 80 | 10 | 5 | 7.644 | 16 | 0.78 | |
2.01 € | 1 | Available | 6 Days | 150.01 to 230.00 | 90 | 10 | 5 | 6.86 | 16 | 0.70 | |
2.26 € | 1 | Available | 6 Days | 150.01 to 230.00 | 100 | 10 | 5 | 6.174 | 16 | 0.63 | |
1.03 € | 1 | 6 Days | 230.01 to 580.00 | 20 | 12 | 6 | 44.394 | 23 | 4.53 | ||
1.07 € | 1 | 6 Days | 230.01 to 580.00 | 25 | 12 | 6 | 35.476 | 23 | 3.62 | ||
1.18 € | 1 | 6 Days | 230.01 to 580.00 | 30 | 12 | 6 | 29.596 | 23 | 3.02 | ||
1.29 € | 1 | 6 Days | 230.01 to 580.00 | 35 | 12 | 6 | 25.284 | 23 | 2.58 | ||
1.29 € | 1 | 6 Days | 230.01 to 580.00 | 40 | 12 | 6 | 22.246 | 23 | 2.27 | ||
1.38 € | 1 | Available | 6 Days | 230.01 to 580.00 | 45 | 12 | 6 | 19.698 | 23 | 2.01 | |
1.49 € | 1 | Available | 6 Days | 230.01 to 580.00 | 50 | 12 | 6 | 17.738 | 23 | 1.81 | |
1.60 € | 1 | Available | 6 Days | 230.01 to 580.00 | 55 | 12 | 6 | 16.072 | 23 | 1.64 | |
1.70 € | 1 | Available | 6 Days | 230.01 to 580.00 | 60 | 12 | 6 | 14.798 | 23 | 1.51 | |
1.74 € | 1 | Available | 6 Days | 230.01 to 580.00 | 65 | 12 | 6 | 13.622 | 23 | 1.39 | |
1.74 € | 1 | Available | 6 Days | 230.01 to 580.00 | 70 | 12 | 6 | 12.642 | 23 | 1.29 | |
1.96 € | 1 | Available | 6 Days | 230.01 to 580.00 | 75 | 12 | 6 | 11.76 | 23 | 1.20 | |
2.05 € | 1 | Available | 6 Days | 230.01 to 580.00 | 80 | 12 | 6 | 11.074 | 23 | 1.13 | |
2.26 € | 1 | Available | 6 Days | 230.01 to 580.00 | 90 | 12 | 6 | 9.898 | 23 | 1.01 | |
2.52 € | 1 | Available | 6 Days | 230.01 to 580.00 | 100 | 12 | 6 | 8.918 | 23 | 0.91 | |
1.38 € | 1 | Available | 6 Days | 230.01 to 580.00 | 20 | 14 | 7 | 59.094 | 31 | 6.03 | |
1.38 € | 1 | Available | 6 Days | 230.01 to 580.00 | 25 | 14 | 7 | 47.726 | 31 | 4.87 | |
1.49 € | 1 | Available | 6 Days | 230.01 to 580.00 | 30 | 14 | 7 | 39.788 | 31 | 4.06 | |
1.60 € | 1 | Available | 6 Days | 230.01 to 580.00 | 35 | 14 | 7 | 34.104 | 31 | 3.48 | |
1.70 € | 1 | Available | 6 Days | 230.01 to 580.00 | 40 | 14 | 7 | 29.792 | 31 | 3.04 | |
1.74 € | 1 | Available | 6 Days | 230.01 to 580.00 | 45 | 14 | 7 | 26.46 | 31 | 2.70 | |
1.85 € | 1 | Available | 6 Days | 230.01 to 580.00 | 50 | 14 | 7 | 23.814 | 31 | 2.43 | |
1.96 € | 1 | Available | 6 Days | 230.01 to 580.00 | 55 | 14 | 7 | 21.658 | 31 | 2.21 | |
2.01 € | 1 | Available | 6 Days | 230.01 to 580.00 | 60 | 14 | 7 | 19.894 | 31 | 2.03 | |
2.05 € | 1 | Available | 6 Days | 230.01 to 580.00 | 65 | 14 | 7 | 18.326 | 31 | 1.87 | |
2.05 € | 1 | Available | 6 Days | 230.01 to 580.00 | 70 | 14 | 7 | 17.052 | 31 | 1.74 | |
2.16 € | 1 | Available | 6 Days | 230.01 to 580.00 | 75 | 14 | 7 | 15.876 | 31 | 1.62 | |
2.16 € | 1 | Available | 6 Days | 230.01 to 580.00 | 80 | 14 | 7 | 14.896 | 31 | 1.52 |
Loading...
Basic information
| Material | AISI-SAE9254 | Color | Red |
|---|
