High-Pressure Pipe Fittings, Screw-in Type Pipe Fittings, SRN Differing Diameter Nipple

High-Pressure Pipe Fittings, Screw-in Type Pipe Fittings, SRN Differing Diameter Nipple
  • Volume Discount
A fitting for medium-pressure and high-pressure piping with general hydraulic pressures. Compatible with pipe schedules.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
SRN02-010J
SRN03-020F
SRN04-020F
SRN04-030F
SRN06-020F
SRN06-030F
SRN06-040F
SRN08-040F
SRN08-060F
SRN12-060F
SRN12-100F
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Thread Nominal M1 Thread Nominal M2

4.97 €

1 Available Same day

Stock

1/4B(8A)1/8B(6A)

3.92 €

1 Available Same day

Stock

3/8B(10A)1/4B(8A)

5.05 €

1 Available Same day

Stock

1/2B(15A)1/4B(8A)

4.81 €

1 Available 5 Days 1/2B(15A)3/8B(10A)

6.68 €

1 Available Same day

Stock

3/4B(20A)1/4B(8A)

10.96 €

1 25 Days 3/4B(20A)3/8B(10A)

6.75 €

1 Available Same day

Stock

3/4B(20A)1/2B(15A)

17.41 €

1 25 Days 1B(25A)1/2B(15A)

17.41 €

1 25 Days 1B(25A)3/4B(20A)

33.55 €

1 Available Same day

Stock

1 1/2B(40A)3/4B(20A)

52.85 €

1 25 Days 1 1/2B(40A)1 1/4B(32A)

Loading...

  1. 1

Basic information

Type Fitting Connection Type Screw⇔Screw Different Diameter Connecting Shape Nipple
Material Carbon steel Connection Thread Type M1 R Connection Thread Type M2 R
Applicable Fluid Oil Interior Resin Lining NA

Tech Support
