VP Pipe (for Pressure Piping / Gray Water)
• Product offers superior corrosion and chemical resistance properties; economical because construction is easier thanks to the lighter weight.
[Application]·
• Drainage piping in housing complexes, detached houses, stores, and facilities.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| VP40X2M |
| VP50X2M |
| VP65X2M |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Diameter (φ) | Nominal Diameter (mm) | D (mm) | t (mm) | JAN Code | Order Code | Mass (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
32.94 € | 1 | 6 Days | 40 | 40 | 48 | 4.0 | 4997983100369 | 446-5733 | 1.6 | ||
46.27 € | 1 | 6 Days | 50 | 50 | 60 | 4.5 | 4997983100376 | 446-5741 | 2.2 | ||
60.07 € | 1 | 6 Days | 65 | 65 | 76 | 4.5 | 4997983100383 | 446-5750 | 2.9 |
Loading...
Basic information
| Type | VP Pipe (Thick) | Length(mm) | 2000 | Material | Vinyl chloride |
|---|---|---|---|---|---|
| Operating Temperature Range [Max. Operating Pressure: 1.0MPa](°C) | 5–35°C | Operating Temperature Range [Max. Operating Pressure: No Pressure](°C) | 5～60°C | Standard | JIS, K6741 Standard Product |
| L(mm) | 2000 | Quantity | 1 |
Configure
Basic Attributes
-
Nominal Diameter(φ)
-
Nominal Diameter(mm)
-
D(mm)
-
t(mm)
-
JAN Code
-
Order Code
-
Type
- VP
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
