One-Touch Fitting KQ2 Series, Triple Universal Male Elbow KQ2VT (Gasket Seal)
One-touch fitting by SMC.
[Features]
· Improved tube insertion and removal.
· Compact, lightweight.
· Can be used in vacuum to -100 kPa.
[Applications]
· Use to branch into three directions at right angles to a female thread. Three individual parts rotate 360°.
[Please refer to the manufacturer's catalog]
· Applicable tube outer diameter (inch) connection thread [UNF] release button oval (P. 40) round (P.145)
[Features]
· Improved tube insertion and removal.
· Compact, lightweight.
· Can be used in vacuum to -100 kPa.
[Applications]
· Use to branch into three directions at right angles to a female thread. Three individual parts rotate 360°.
[Please refer to the manufacturer's catalog]
· Applicable tube outer diameter (inch) connection thread [UNF] release button oval (P. 40) round (P.145)
(i)Remark
- Please refer to the catalog for detailed specifications and materials.
- Product images may be representative images. Refer to the catalog for details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| KQ2VT01-32A |
| KQ2VT01-32N |
| KQ2VT03-32A |
| KQ2VT03-32N |
| KQ2VT07-32A |
| KQ2VT07-32N |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Main Body Material | Thread Material | |
|---|---|---|---|---|---|---|
19.40 € | 10 | 26 Days | [Flame Resistant Resin (UL94 V-0)] Flame Retardant PBT (Ul94 V-0 Equivalent) | [PP Resin] PP | ||
19.56 € | 10 | 26 Days | [Brass] Brass | [Standard (Brass)] EN 1.4305 Equiv., EN 1.4301 Equiv. | ||
19.40 € | 10 | 26 Days | [Flame Resistant Resin (UL94 V-0)] Flame Retardant PBT (Ul94 V-0 Equivalent) | [PP Resin] PP | ||
19.56 € | 10 | 26 Days | [Brass] Brass | [Standard (Brass)] EN 1.4305 Equiv., EN 1.4301 Equiv. | ||
30.45 € | 10 | 26 Days | [Flame Resistant Resin (UL94 V-0)] Flame Retardant PBT (Ul94 V-0 Equivalent) | [PP Resin] PP | ||
30.68 € | 10 | 26 Days | [Brass] Brass | [Standard (Brass)] EN 1.4305 Equiv., EN 1.4301 Equiv. |
Loading...
Basic information
| Type | Single-Action / Screw | Fitting Type | Screw Mount Branch | Applicable Fluid | Water / Air |
|---|---|---|---|---|---|
| Application | Standard/Mini | Packing, Material of O-Ring | EPDM (Fluorine Coating) | Screw Mounting, Branch | Triple Universal Elbow |
| Connection Type | UNF | Connection screw | 10-32 | Number of Connection Tubes(pc.) | 3 |
| Color | White | Release button shape | Perfect circle | Release button color | Orange |
- Product images may be representative images. Refer to the catalog for details.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
