Male Run Tee 10-KQ2Y (Sealant), One-Touch Fitting
[Features]
· One-touch insertion and removal.
· Can be used in vacuum to -100 kPa.
[Applications]
· Use to branch in line with and at a 90° angle to a female thread.
(i)Remark
- Please refer to the catalog for detailed specifications and materials.
- Product images may be representative images. Refer to the catalog for details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Compatible Tube Outer Diameter 1 (mm) | Connection Type | Connection screw | |
|---|---|---|---|---|---|---|---|
5.23 € | 10 | 26 Days | 4 | R | 1/8 | ||
5.39 € | 10 | 26 Days | 4 | R | 1/4 | ||
5.35 € | 10 | 26 Days | 6 | R | 1/8 | ||
5.56 € | 10 | 26 Days | 6 | R | 1/4 | ||
5.89 € | 10 | 26 Days | 6 | R | 3/8 | ||
6.52 € | 10 | 6 Days | - | NPT | 1/8 | ||
5.79 € | 10 | 26 Days | 8 | R | 1/8 | ||
5.94 € | 10 | 26 Days | 8 | R | 1/4 | ||
6.23 € | 10 | 26 Days | 8 | R | 3/8 | ||
7.11 € | 10 | 6 Days | - | R | 1/8 | ||
7.65 € | 5 | 26 Days | 10 | R | 1/8 | ||
7.68 € | 5 | 26 Days | 10 | R | 1/4 | ||
8.02 € | 5 | 26 Days | 10 | R | 3/8 | ||
8.52 € | 5 | 26 Days | 10 | R | 1/2 | ||
9.15 € | 5 | 26 Days | - | R | 1/4 | ||
9.18 € | 5 | 26 Days | - | R | 3/8 | ||
9.18 € | 5 | 26 Days | - | R | 1/2 | ||
14.23 € | 5 | 26 Days | - | R | 1/4 | ||
14.24 € | 5 | 26 Days | - | R | 3/8 | ||
14.44 € | 5 | 26 Days | - | R | 1/2 | ||
5.23 € | 10 | 26 Days | - | R | 1/8 | ||
5.39 € | 10 | 26 Days | - | R | 1/4 |
Loading...
Basic information
| Type | Single-Action / Screw | Fitting Type | Screw Mount Branch | Applicable Fluid | Water / Air |
|---|---|---|---|---|---|
| Main Body Material | PP | Application | Clean circumstance | Thread Material | EN 1.4305 Equiv., EN 1.4301 Equiv. |
| Packing, Material of O-Ring | EPDM (Fluorine Coating) | Screw Mounting, Branch | Service Tee Union | Number of Connection Tubes(pc.) | 2 |
| Color | White | Specifications | With sealing agent | Release button shape | Perfect circle |
| Release button color | White | Custom-made specifications | N/A |
- Product images may be representative images. Refer to the catalog for details.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
