PPA, Compact Manometer
[Features]
· Compact and lightweight
· Includes a backlight for easy viewing in dark locations
· Long service life of 12 months continuous operation
· With a convenient handstrap for carrying
· Zero/span calibration is possible
· Has a peak / bottom hold function
(i)Remark
- See catalog for specification details.
- Product pictures are representations. CAD data is not supported for some model numbers.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Type | Maximum Indicated Pressure (Mpa) | Connection screw | Option | Indicated Pressure Range | Pressure Specifications | Applicable Tube Size | Unit Specifications | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
173.21 € | 1 | 26 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 1 | Female thread (M5 × 0.8) | None | -0.1 to 1 MPa | For high pressure | - | With unit conversion function | ||
176.98 € | 1 | 31 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 1 | Single-action fittings | None | -0.1 to 1 MPa | For high pressure | ø4 | With unit conversion function | ||
185.02 € | 1 | 26 Days | - | - | Single-action fittings | With case holder (PPA-B) | -0.1 to 1 MPa | For high pressure | ø4 | With unit conversion function | ||
185.02 € | 1 | 26 Days | - | - | Single-action fittings | With case holder (PPA-B) | -0.1 to 1 MPa | For high pressure | ø4 | SI unit fixed | ||
177.11 € | 1 | 4 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 1 | Single-action fittings | None | -0.1 to 1 MPa | For high pressure | ø6 | With unit conversion function | ||
185.13 € | 1 | 39 Days | - | - | Single-action fittings | With case holder (PPA-B) | -0.1 to 1 MPa | For high pressure | ø6 | With unit conversion function | ||
215.35 € | 1 | 26 Days | - | - | - | - | - | - | - | - | ||
206.90 € | 1 | Quote | - | - | - | - | - | - | - | - | ||
181.23 € | 1 | 4 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 1 | Female thread (M5 × 0.8) | With case holder (PPA-B) | -0.1 to 1 MPa | For high pressure | - | With unit conversion function | ||
181.23 € | 1 | 26 Days | - | - | Female thread (M5 × 0.8) | With case holder (PPA-B) | -0.1 to 1 MPa | For high pressure | - | SI unit fixed | ||
173.21 € | 1 | 26 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 1 | Female thread (M5 × 0.8) | None | -0.1 to 1 MPa | For high pressure | - | SI unit fixed | ||
192.68 € | 1 | 26 Days | - | - | - | - | - | - | - | - | ||
173.21 € | 1 | 26 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 0.01 | Female thread (M5 × 0.8) | None | -101 to 10 kPa | For vacuum | - | With unit conversion function | ||
176.98 € | 1 | 26 Days | - | - | Single-action fittings | None | -101 to 10 kPa | For vacuum | ø4 | With unit conversion function | ||
194.65 € | 1 | 26 Days | - | - | Single-action fittings | With case holder (PPA-B) | -101 to 10 kPa | For vacuum | ø4 | With unit conversion function | ||
196.47 € | 1 | 26 Days | - | - | - | - | - | - | - | - | ||
177.11 € | 1 | 4 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 0.01 | Single-action fittings | None | -101 to 10 kPa | For vacuum | ø6 | With unit conversion function | ||
185.13 € | 1 | 4 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 0.01 | Single-action fittings | With case holder (PPA-B) | -101 to 10 kPa | For vacuum | ø6 | With unit conversion function | ||
181.16 € | 1 | 26 Days | - | - | Female thread (M5 × 0.8) | With case holder (PPA-B) | -101 to 10 kPa | For vacuum | - | With unit conversion function | ||
173.24 € | 1 | 26 Days | - | - | Female thread (M5 × 0.8) | None | -101 to 10 kPa | For vacuum | - | SI unit fixed | ||
192.68 € | 1 | 26 Days | - | - | - | - | - | - | - | - | ||
173.21 € | 1 | 4 Days | Bottom Mount / Compact / Mount-Type Pressure Gauge | 0.1 | Female thread (M5 × 0.8) | None | -10 to 100 kPa | For low pressure | - | With unit conversion function | ||
176.98 € | 1 | 26 Days | - | - | Single-action fittings | None | -10 to 100 kPa | For low pressure | ø4 | With unit conversion function | ||
185.02 € | 1 | 26 Days | - | - | Single-action fittings | With case holder (PPA-B) | -10 to 100 kPa | For low pressure | ø4 | With unit conversion function | ||
196.47 € | 1 | 26 Days | - | - | - | - | - | - | - | - | ||
177.11 € | 1 |
Same day
Stock | - | - | Single-action fittings | None | -10 to 100 kPa | For low pressure | ø6 | With unit conversion function | ||
185.13 € | 1 | 26 Days | - | - | Single-action fittings | With case holder (PPA-B) | -10 to 100 kPa | For low pressure | ø6 | With unit conversion function | ||
181.23 € | 1 | 26 Days | - | - | Female thread (M5 × 0.8) | With case holder (PPA-B) | -10 to 100 kPa | For low pressure | - | With unit conversion function | ||
192.68 € | 1 | 26 Days | - | - | - | - | - | - | - | - |
Loading...
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Type
- Bottom Mount / Compact / Mount-Type Pressure Gauge
-
Maximum Indicated Pressure(Mpa)
-
Connection screw
- Female thread (M5 × 0.8)
- Single-action fittings
-
Option
- None
- With case holder (PPA-B)
-
Indicated Pressure Range
- -101 to 10 kPa
- -10 to 100 kPa
- -0.1 to 1 MPa
-
Pressure Specifications
- For high pressure
- For low pressure
- For vacuum
-
Applicable Tube Size
- ø4
- ø6
-
Unit Specifications
- SI unit fixed
- With unit conversion function
-
Type
- PPA100
- PPA101
- PPA102
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 4 Days or Less
- 26 Days or Less
- 31 Days or Less
- 39 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
