ANA1, High Noise Reduction Silencer - 40dB(A)

ANA1, High Noise Reduction Silencer - 40dB(A)

SMC

SMC

[Features]
· High noise reduction silencer that achieves 85 dB (A) or lower when tested in our factory.
· Fluid: compressed air.
· Maximum operating pressure: 1.0 MPa (*Shows the primary-side pressure of the solenoid valve).
· Noise reduction effect: 40 dB (A) (*May change depending on the air pressure circuit, pressure, etc., from which the exhaust is emitted).
· Ambient temperature and operating fluid temperature: 5 to 60°C.
*Can be used at between -10 to +60°C as long as there is no risk of water drops being generated from the fluid and freezing.

(i)Remark

  • Refer to the catalog for product specifications.
  • Product images may be representative images. Refer to the catalog for details.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
ANA1-01
ANA1-02
ANA1-03
ANA1-04
ANA1-06
ANA1-10
ANA1-12
ANA1-14
ANA1-20
ANA1-C08
ANA1-C10
ANA1-C12
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Main Body Material Pipe Connection Port Type Cover Element Material Effective Sectional Area
(mm2) 		Effective Sectional Area【classification】
(mm2) 		Mounting Thread Nominal One-Touch Fitting Size Outer Diameter D
(Ø) 		Recommended Flow Rate
(m3/min(ANR)) 		Length A
(mm)

7.03 €

1 3 Days [Resin] Resin[Flange] 4B(100A)JIS 10K FF FlangeNA[Resin Group] Resin Based10Up to 10[1/8] 1/8-160.8 or less37

9.27 €

1 4 Days [Resin] Resin[Flange] 4B(100A)JIS 10K FF FlangeNA[Resin Group] Resin Based15Up to 15[1/4] 1/4-221.2 or less64

9.97 €

1 Same day

Stock

[Resin] Resin[Flange] 4B(100A)JIS 10K FF FlangeNA[Resin Group] Resin Based35Up to 40[3/8] 3/8-252.7 or less84

14.32 €

1 3 Days [Resin] Resin[Flange] 4B(100A)JIS 10K FF FlangeNA[Resin Group] Resin Based60Up to 60[1 1/4] 1 1/4-304.5 or less98

24.06 €

1 Same day

Stock

[Resin] Resin[Flange] 4B(100A)JIS 10K FF FlangeNA[Resin Group] Resin Based90Up to 90--467.0 or less111

33.81 €

1 Same day

Stock

[Aluminum] Aluminum[Flange] 4B(100A)JIS 10K FF FlangeAvailable[Resin Group] Sintered Resin160Up to 200[1/8] 1/8-5012.0 or less132

61.31 €

1 Same day

Stock

[Aluminum] Aluminum[Flange] 4B(100A)JIS 10K FF FlangeAvailable[Resin Group] Sintered Resin280Up to 300[1 1/4] 1 1/4-7420.0 or less200

67.10 €

1 4 Days [Aluminum] Aluminum[Flange] 4B(100A)JIS 10K FF FlangeAvailable[Resin Group] Sintered Resin450Up to 500[1 1/2] 1 1/2-7432.0 or less230

88.81 €

1 Same day

Stock

[Aluminum] Aluminum[Flange] 4B(100A)JIS 10K FF FlangeAvailable[Resin Group] Sintered Resin610Up to 700[1] 1-8645.0 or less271

8.73 €

1 Same day

Stock

[Resin] ResinSingle-Action PipeNA[Resin Group] Resin Based11Up to 15-φ8160.8 or less58

11.06 €

1 Same day

Stock

[Resin] ResinSingle-Action PipeNA[Resin Group] Resin Based15Up to 15-φ10221.2 or less76

12.10 €

1 4 Days [Resin] ResinSingle-Action PipeNA[Resin Group] Resin Based33Up to 40-φ12252.5 or less95
