GP46, Pressure Gauge w / Switch (O.D. 42.5)
· A pressure switch function has been added to the gauge
· The pressure switch has a light to confirm operation
· The pressure gauge includes a limit indicator
· Used to confirm supply pressure
(i)Remark
- Product images may be representative images. Refer to the manufacturer's catalog for details
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Type | Maximum Indicated Pressure (Mpa) | Outer Diameter (φ) | Connection screw | Option | Special Specification | Indication lamp addition symbol | Attachment | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
57.98 € | 1 | 4 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 57 | R 1⁄8 | - | CE marked | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
50.34 € | 1 | 26 Days | - | - | - | R 1⁄8 | - | Lead wire length 3 m | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 61 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 42.5 | R 1⁄8 | - | CE marked | Without light | Without cover ring assembly | ||
57.98 € | 1 | 26 Days | - | - | - | R 1⁄8 | - | CE marked | With neon light / 100 to 220 V AC common | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 26 Days | - | - | - | R 1⁄8 | - | CE marked | With neon light / 100 to 220 V AC common | Without cover ring assembly | ||
57.98 € | 1 | 28 Days | - | - | - | R 1⁄8 | - | CE marked | Light-emitting diode / 24 V DC | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 33 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 42.5 | R 1⁄8 | - | CE marked | Light-emitting diode / 24 V DC | Without cover ring assembly | ||
59.77 € | 1 | 26 Days | - | - | - | R 1⁄8 | With M5 (female thread) | - | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
62.82 € | 1 | 26 Days | - | - | - | R 1⁄8 | With M5 (female thread) | Lead wire length 3 m | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
55.74 € | 1 | 26 Days | - | - | - | R 1⁄8 | With M5 (female thread) | CE marked | Without light | Without cover ring assembly | ||
75.98 € | 1 | 26 Days | - | - | - | R 1⁄8 | With M5 (female thread) | CE marked | Light-emitting diode / 24 V DC | Clear cover has no protrusion (clear cover cannot be removed) | ||
55.68 € | 1 | 26 Days | - | - | - | R 1⁄8 | With M5 (female thread) | CE marked | Light-emitting diode / 24 V DC | Without cover ring assembly | ||
58.03 € | 1 | 26 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 57 | R1/4 | - | - | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
57.98 € | 1 | 26 Days | - | - | - | R1/4 | - | CE marked | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
50.34 € | 1 | 26 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 57 | R1/4 | - | Lead wire length 3 m | Without light | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 25 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 42.5 | R1/4 | - | CE marked | Without light | Without cover ring assembly | ||
57.98 € | 1 | 26 Days | - | - | - | R1/4 | - | CE marked | With neon light / 100 to 220 V AC common | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 26 Days | - | - | - | R1/4 | - | CE marked | With neon light / 100 to 220 V AC common | Without cover ring assembly | ||
59.44 € | 1 | Quote | - | - | - | R1/4 | - | Lead wire length 3 m | With neon light / 100 to 220 V AC common | Without cover ring assembly | ||
57.98 € | 1 | 26 Days | Other Pressure Gauge / Peripheral Accessories | 1 | 57 | R1/4 | - | - | Light-emitting diode / 24 V DC | Clear cover has no protrusion (clear cover cannot be removed) | ||
57.98 € | 1 | 26 Days | - | - | - | R1/4 | - | CE marked | Light-emitting diode / 24 V DC | Clear cover has no protrusion (clear cover cannot be removed) | ||
61.73 € | 1 | 26 Days | - | - | - | R1/4 | - | Lead wire length 3 m | Light-emitting diode / 24 V DC | Clear cover has no protrusion (clear cover cannot be removed) | ||
52.08 € | 1 | 26 Days | - | - | - | R1/4 | - | CE marked | Light-emitting diode / 24 V DC | Without cover ring assembly |
Loading...
Basic information
| Shape | Back side thread | Maximum Indicated Pressure | 1.0 MPa |
|---|
Configure
Basic Attributes
-
Type
- Other Pressure Gauge / Peripheral Accessories
-
Maximum Indicated Pressure(Mpa)
-
Outer Diameter(φ)
-
Connection screw
- R1/4
- R 1⁄8
-
Option
- With M5 (female thread)
-
Special Specification
- Lead wire length 3 m
- CE marked
-
Indication lamp addition symbol
- Light-emitting diode / 24 V DC
- With neon light / 100 to 220 V AC common
- Without light
-
Attachment
- Clear cover has no protrusion (clear cover cannot be removed)
- Without cover ring assembly
-
Type
- GP46
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 4 Days or Less
- 25 Days or Less
- 26 Days or Less
- 28 Days or Less
- 33 Days or Less
- 61 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
