AC Series Air Combination Piping Adapter
[Features]
· Attachment for AC Series Air Combination.
· E100-M5-A applicable model: AC10□-A.
· E200-□01-A, 02-A, 03-A applicable model: AC20□-A.
· E300-□02-A, 03-A, 04-A applicable models: AC25□-A, AC30□-A.
· E400-□02-A, 03-A, 04-A, □06-A applicable model: AC40□-A.
· E500-□06-A applicable model: AC40□-06-A.
(i)Remark
- Refer to the manufacturer's catalog for specification and material details.
- Product images may be representative images. Refer to the manufacturer's catalog for shape details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Connection Diameter | Compatible models | |
|---|---|---|---|---|---|---|
2.92 € | 1 | 39 Days | M5 | AC10□-A | ||
3.13 € | 1 | 37 Days | Rc1/8 | AC20□-B | ||
3.13 € | 1 | 37 Days | Rc1/4 | AC20□-B | ||
3.13 € | 1 | Quote | Rc3/8 | AC20□-B | ||
3.13 € | 1 | 4 Days | G1/8 | AC20□-B | ||
3.13 € | 1 | 4 Days | G1/4 | AC20□-B | ||
3.13 € | 1 | 4 Days | G3/8 | AC20□-B | ||
3.13 € | 1 | 37 Days | NPT1/8 | AC20□-B | ||
3.13 € | 1 | Quote | NPT1/4 | AC20□-B | ||
3.13 € | 1 | Quote | NPT3/8 | AC20□-B | ||
4.29 € | 1 | 37 Days | Rc1/4 | AC25□-B, AC30□-B | ||
4.29 € | 1 | 39 Days | Rc3/8 | AC25□-B, AC30□-B | ||
4.65 € | 1 | 37 Days | Rc1/2 | AC25□-B, AC30□-B | ||
4.29 € | 1 | 39 Days | G1/4 | AC25□-B, AC30□-B | ||
4.29 € | 1 | 4 Days | G3/8 | AC25□-B, AC30□-B | ||
4.65 € | 1 | 4 Days | G1/2 | AC25□-B, AC30□-B | ||
4.29 € | 1 | 37 Days | NPT1/4 | AC25□-B, AC30□-B | ||
4.29 € | 1 | 37 Days | NPT3/8 | AC25□-B, AC30□-B | ||
4.65 € | 1 | Quote | NPT1/2 | AC25□-B, AC30□-B | ||
5.06 € | 1 | 37 Days | Rc1/4 | AC40□-B | ||
5.06 € | 1 | 37 Days | Rc3/8 | AC40□-B | ||
5.06 € | 1 | Quote | Rc1/2 | AC40□-B | ||
5.48 € | 1 | 37 Days | Rc3/4 | AC40□-B | ||
5.06 € | 1 | 4 Days | G1/4 | AC40□-B | ||
5.06 € | 1 | 4 Days | G3/8 | AC40□-B | ||
5.06 € | 1 | 4 Days | G1/2 | AC40□-B | ||
5.48 € | 1 | 4 Days | G3/4 | AC40□-B | ||
5.06 € | 1 | 37 Days | NPT1/4 | AC40□-B | ||
5.06 € | 1 | Quote | NPT3/8 | AC40□-B | ||
5.06 € | 1 |
Quote
Stock | NPT1/2 | AC40□-B | ||
5.48 € | 1 | 37 Days | NPT3/4 | AC40□-B | ||
6.56 € | 1 | 37 Days | Rc3/4 | AC40□-06-B | ||
6.56 € | 1 |
Quote
Stock | G3/4 | AC40□-06-B | ||
6.56 € | 1 | 37 Days | NPT3/4 | AC40□-06-B | ||
12.05 € | 1 | Quote | Rc1 | AC50-B, AC55-B, AC60-B, AC50A-B, AC60A-B, AC50B-B, AC55B-B, AC60B-B | ||
12.31 € | 1 | 4 Days | G3/4 | AC50-B, AC55-B, AC60-B, AC50A-B, AC60A-B, AC50B-B, AC55B-B, AC60B-B | ||
12.71 € | 1 | 39 Days | G1 | AC50-B, AC55-B, AC60-B, AC50A-B, AC60A-B, AC50B-B, AC55B-B, AC60B-B | ||
12.05 € | 1 | Quote | NPT1 | AC50-B, AC55-B, AC60-B, AC50A-B, AC60A-B, AC50B-B, AC55B-B, AC60B-B |
Loading...
Basic information
| Regulator Unit Combination | Adapter |
|---|
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Connection Diameter
- Rc1/8
- Rc1/4
- Rc3/8
- Rc1/2
- Rc3/4
- Rc1
- NPT1/4
- NPT3/8
- G1/4
- G3/8
- NPT1/2
- NPT3/4
- NPT1/8
- NPT1
- G1/8
- G1/2
- G3/4
- G1
- M5
-
Compatible models
- AC10□-A
- AC20□-B
- AC25□-B, AC30□-B
- AC40□-B
- AC40□-06-B
- AC50-B, AC55-B, AC60-B, AC50A-B, AC60A-B, AC50B-B, AC55B-B, AC60B-B
-
Type
- E100-□-A
- E200-□-A
- E300-□-A
- E400-□-A
- E500-□-A
- E600-□-A
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 4 Days or Less
- 37 Days or Less
- 39 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
