IDFA3~75E, Refrigerated Air Dryer
[Features]
· Power supply voltage: Single-phase 230 V AC (50 Hz).
· Auto drain: Float type (normally open).
· Coating color: Body panel: urban white 1, Base: urban gray 2.
· Compliant standards: EC directive (CE marking).
(i)Remark
- ■ SMC Product Line
Webpages for products currently without individual pages on this site will be released on an ad-hoc basis.
■ Products Planned for Online Release
Air cylinder-related product pages will be released on this site on an ad-hoc basis.
CQ2/MG types, etc., are already available.
*Vacuum equipment, FRLs, solenoid valves, etc., will also be released on dedicated pages on this site on an ad-hoc basis.
*The information above is correct as of December 2018. - See catalog for specification details.
- Product images may be representative images. Refer to the manufacturer's catalog for shape details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Air Inlet Flow Rate [Distinction] (l/min) | Air Inlet Flow (l/min) | Supply Side, Nominal Designation of Piping Thread | Control SideNominal Pipe Threads | Standard size | Auto drain | Copper Tube Anti-rust Processing | For medium pressure air | Leakage Circuit Breaker | Operation, Terminal block for abnormal signal takeout | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3,009.41 € | 1 | 39 Days | Up to 5000 | 3,033 / 3,850 / 4,233 | 1 | 1 | 22E | With heavy-duty auto drain | None | None | None | None | ||
3,748.79 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | Yes | None | None | None | ||
3,906.27 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | Yes | For medium-pressure air (Case for auto drain: metal case with level gauge) | None | None | ||
4,142.64 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With heavy-duty auto drain | Yes | None | None | None | ||
4,723.37 € | 1 | Quote | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With heavy-duty auto drain | Yes | None | Yes | None | ||
4,893.20 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | Yes | None | Yes | Yes | ||
4,312.47 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | Yes | None | None | Yes | ||
3,978.29 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With a timer-controlled solenoid valve type auto drain | Yes | None | None | None | ||
4,100.79 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | None | For medium-pressure air (Case for auto drain: metal case with level gauge) | None | Yes | ||
3,773.47 € | 1 | 82 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With heavy-duty auto drain | None | None | None | None | ||
4,337.16 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With heavy-duty auto drain | None | None | None | Yes | ||
3,960.31 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | None | None | Yes | None | ||
4,524.03 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | None | None | Yes | Yes | ||
4,753.53 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With a timer-controlled solenoid valve type auto drain | None | None | Yes | Yes | ||
3,943.30 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | None | None | None | None | Yes | ||
4,172.79 € | 1 | 26 Days | More than 5000 | 4,550 / 5,783 / 6,366 | 1 1/2 | 1 1/2 | 37E | With a timer-controlled solenoid valve type auto drain | None | None | None | Yes | ||
5,927.23 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | None | None | None | None | None | ||
6,456.80 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | None | Yes | None | None | None | ||
6,946.14 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | With heavy-duty auto drain | Yes | None | None | None | ||
6,707.01 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | With a timer-controlled solenoid valve type auto drain | Yes | None | None | None | ||
7,194.80 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | With heavy-duty auto drain | None | None | None | Yes | ||
6,705.43 € | 1 | Quote | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | None | None | None | None | Yes | ||
6,177.43 € | 1 | 26 Days | More than 5000 | 6,500 / 7,200 / 8,500 | 2 | 2 | 55E | With a timer-controlled solenoid valve type auto drain | None | None | None | None | ||
7,428.90 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | None | None | None | None | ||
7,958.54 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | Yes | None | None | None | ||
8,447.96 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With heavy-duty auto drain | Yes | None | None | None | ||
9,181.41 € | 1 | 26 Days | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With heavy-duty auto drain | Yes | None | Yes | None | ||
9,358.41 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With heavy-duty auto drain | Yes | None | None | Yes | ||
9,602.53 € | 1 | 26 Days | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | Yes | None | Yes | Yes | ||
9,114.16 € | 1 | 26 Days | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With a timer-controlled solenoid valve type auto drain | Yes | None | None | Yes | ||
8,203.71 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With a timer-controlled solenoid valve type auto drain | Yes | None | None | None | ||
8,828.76 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With heavy-duty auto drain | None | None | None | Yes | ||
8,162.50 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | None | None | Yes | None | ||
9,072.96 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | None | None | Yes | Yes | ||
8,339.41 € | 1 | Quote | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | None | None | None | None | Yes | ||
7,674.07 € | 1 | 26 Days | More than 5000 | 11,000 / 12,000 / 13,700 | 2 | 2 | 75E | With a timer-controlled solenoid valve type auto drain | None | None | None | None |
Loading...
Basic information
| Method | Refrigerating type (air-cooling specification) | Shape | Standard | Exit Air Atmospheric Pressure Dew Point(°C) | 3 / 10 / 7 |
|---|---|---|---|---|---|
| Supply Side, Connection Type | R | Air Temperature at the Inlet Port(°C) | 35 | Air Pressure at the Inlet Port Side(MPa) | 0.7 |
| Control Side Connection Types | R | Power Supply Voltage | Single-phase: 230 V AC (50 Hz) | Chinese nameplate, Chinese operation manual | None |
Configure
Basic Attributes
-
Air Inlet Flow Rate [Distinction](l/min)
-
Air Inlet Flow(l/min)
-
Supply Side, Nominal Designation of Piping Thread
- 1
- 1 1/2
- 2
-
Control SideNominal Pipe Threads
- 1
- 1 1/2
- 2
-
Standard size
-
Auto drain
- None
- With a timer-controlled solenoid valve type auto drain
- With heavy-duty auto drain
-
Copper Tube Anti-rust Processing
- None
- Yes
-
For medium pressure air
- For medium-pressure air (Case for auto drain: metal case with level gauge)
- None
-
Leakage Circuit Breaker
- None
- Yes
-
Operation, Terminal block for abnormal signal takeout
- None
- Yes
-
Type
- IDFA22E
- IDFA37E
- IDFA55E
- IDFA75E
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 26 Days or Less
- 39 Days or Less
- 82 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
