Mechanical joint type rodless cylinder linear guide type 55-MY1H series
(i)Remark
- ■ SMC Air Cylinder Product Selection and Technical Information
Please check the special page from here.
■About SMC product handling
products without a web page will be released one by one.
If you have a fixed model number, please request a quote / order from here. - Refer to the manufacturer's catalog for specification and material details.
- Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 55-MY1H25-450Z |
| 55-MY1H25G-350Z |
| 55-MY1H32-300Z |
| 55-MY1H40-300Z |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Stroke (mm) | Max. Load Mass (Range Selectable) (kg) | Max. Load Mass (kg) | Table Size Length L (mm) | Cylinder Inner Diameter (Ø) | Table Size Width W (mm) | Table Size Height H (mm) | Piping Format | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
1,173.26 € | 1 | 26 Days | 450 | 20~39.9 | 27.5 | 114 | 25 | 90 | 54 | Standard type | ||
1,110.84 € | 1 | 26 Days | 350 | 20~39.9 | 27.5 | 114 | 25 | 90 | 54 | Centralized piping type | ||
1,223.21 € | 1 | 26 Days | 300 | 20~39.9 | 39.2 | 140 | 32 | 110 | 68 | Standard type | ||
1,513.98 € | 1 | 26 Days | 300 | 40~57 | 50 | 170 | 40 | 121 | 84 | Standard type |
Loading...
Basic information
| Type | Rodless Cylinder | Table Material | Aluminum Alloy | Rodless Cylinder Joint Type | Mechanically Jointed |
|---|---|---|---|---|---|
| Usage Environment | General Purpose | Table Surface Treatment | Hard Anodized Aluminum | Guide | Linear guide type |
| Operating Pressure(MPa) | 0.1 to 0.8 | Port Screw Type | Rc | Custom-made | Standard |
Configure
Basic Attributes
-
Stroke(mm)
-
Max. Load Mass (Range Selectable)(kg)
-
Max. Load Mass(kg)
-
Table Size Length L(mm)
-
Cylinder Inner Diameter(Ø)
-
Table Size Width W(mm)
-
Table Size Height H(mm)
-
Piping Format
-
Type
- 55-MY1H25
- 55-MY1H32
- 55-MY1H40
Filter by standard shipping days
-
- All
- 26 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
