Pressure gauge, PAGL Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| PAGL-HP3-63-60-G14 |
| PAGL-HP3-63-60-G14-RC |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Connection position | Manufacturer part # | |
|---|---|---|---|---|---|---|---|
179.60 € | 1 | 4 Days | Centered on rear side | 0001166938 | |||
179.60 € | 1 | 4 Days | Radial at bottom | 0001908519 |
Loading...
Basic information
| Pressure gauge nominal size | 63 | Pneumatic connection | G1/4 | Housing material | Steel |
|---|---|---|---|---|---|
| Material of screwed trunnion | Brass | Inspection window material | PS | Housing colour | Silver |
| Degree of protection | IP65 | Min. Operating pressure(bar) | 0 | Max. Operating pressure(bar) | 60 |
| Min. Temperature of medium(°C) | 0 | Max. Temperature of medium(°C) | 60 | Min. Ambient temperature(°C) | 0 |
| Max. Ambient temperature(°C) | 60 | Min. Storage temperature(°C) | -40 | Max. Storage temperature(°C) | 70 |
| Operating medium | Inert gas, Neutral liquids | Weight(g) | 80 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
