Front panel valve, SV Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| SV-3-M5 |
| SV-5-M5-B |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Valve function | Standard nominal flow rate (l/min) | Nominal width (mm) | Min. Operating pressure (bar) | Actuating force (N) | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
54.52 € | 1 | 3 Days | 3/2, closed, monostable | 65 | 2 | -0.95 | 12 | 6817 | 40 | |||
79.06 € | 1 | 7 Days | 5/2, monostable | 95 | 2.3 | 0 | 17 | 11914 | 53 |
Loading...
Basic information
| Housing material | Brass, Polymer | Seals material | NBR | Lap | Overlap |
|---|---|---|---|---|---|
| Pneumatic connection 1 | M5 | Max. Operating pressure(bar) | 8 | Min. Ambient temperature(°C) | -10 |
| Max. Ambient temperature(°C) | 60 | Operating medium | Compressed air as per ISO 8573-1:2010 [-:-:-] |
Configure
Basic Attributes
-
Valve function
-
Standard nominal flow rate(l/min)
-
Nominal width(mm)
-
Min. Operating pressure(bar)
-
Actuating force(N)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
