Filter regulator, MS6 Series
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Filter, Filtration Level | Bowl guard | Standard nominal flow rate (l/min) | Pneumatic connection 1 | Pneumatic connection 2 | Material of bowl | Min. Operating pressure (bar) | Max. Operating pressure (bar) | Min. Pressure regulation range (bar) | Max. Pressure regulation range (bar) | Min. Temperature of medium (°C) | Min. Ambient temperature (°C) | Operating medium | Air quality class at the output | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
83.12 € | 1 | 4 Days | 5 μm | Plastic bowl guard | 5600 | G1/2 | G1/2 | PC | 0.8 | 20 | 0.3 | 7 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529176 | 875 | |||
113.95 € | 1 | 3 Days | 5 μm | Plastic bowl guard | 5600 | G1/2 | G1/2 | PC | 2 | 12 | 0.3 | 7 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529178 | 875 | |||
83.12 € | 1 | 4 Days | 40µm | Plastic bowl guard | 6200 | G1/2 | G1/2 | PC | 0.8 | 20 | 0.3 | 7 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529180 | 875 | |||
113.95 € | 1 | 4 Days | 40µm | Plastic bowl guard | 6200 | G1/2 | G1/2 | PC | 2 | 12 | 0.3 | 7 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529182 | 875 | |||
83.12 € | 1 | 3 Days | 5 μm | Plastic bowl guard | 4000 | G1/2 | G1/2 | PC | 0.8 | 20 | 0.5 | 12 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529184 | 875 | |||
113.95 € | 1 | 3 Days | 5 μm | Plastic bowl guard | 4000 | G1/2 | G1/2 | PC | 2 | 12 | 0.5 | 12 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529186 | 875 | |||
110.31 € | 1 | 4 Days | 5 μm | Integrated as metal bowl guard | 4000 | G1/2 | G1/2 | Wrought aluminum alloy | 0.8 | 20 | 0.5 | 12 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 530338 | 1087 | |||
141.12 € | 1 | 4 Days | 5 μm | Integrated as metal bowl guard | 4000 | G1/2 | G1/2 | Wrought aluminum alloy | 2 | 12 | 0.5 | 12 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 530340 | 1087 | |||
83.12 € | 1 | 3 Days | 40µm | Plastic bowl guard | 4500 | G1/2 | G1/2 | PC | 0.8 | 20 | 0.5 | 12 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529188 | 875 | |||
113.95 € | 1 | 3 Days | 40µm | Plastic bowl guard | 4500 | G1/2 | G1/2 | PC | 2 | 12 | 0.5 | 12 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529190 | 875 | |||
110.31 € | 1 | 3 Days | 40µm | Integrated as metal bowl guard | 4500 | G1/2 | G1/2 | Wrought aluminum alloy | 0.8 | 20 | 0.5 | 12 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529192 | 1087 | |||
83.12 € | 1 | 7 Days | 40µm | Plastic bowl guard | 2500 | G1/4 | G1/4 | PC | 0.8 | 20 | 0.5 | 12 | -10 | -10 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529208 | 875 | |||
113.95 € | 1 | 4 Days | 40µm | Plastic bowl guard | 2500 | G1/4 | G1/4 | PC | 2 | 12 | 0.5 | 12 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529210 | 875 | |||
113.95 € | 1 | 4 Days | 5 μm | Plastic bowl guard | 5000 | G3/8 | G3/8 | PC | 2 | 12 | 0.3 | 7 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [7:4:4] | Compressed air as per ISO 8573-1:2010 [-:4:-], Inert gas | 529218 | 875 | |||
113.95 € | 1 | 7 Days | 40µm | Plastic bowl guard | 4000 | G3/8 | G3/8 | PC | 2 | 12 | 0.5 | 12 | 5 | 5 | Compressed air as per ISO 8573-1:2010 [6:4:4] | Compressed air as per ISO 8573-1:2010 [7:4:-], Inert gas | 529230 | 875 |
Loading...
Basic information
| Pressure gauge | with pressure gauge | Max. condensate volume(ml) | 38 | Max. pressure hysteresis(bar) | 0.25 |
|---|---|---|---|---|---|
| Housing material | Die-cast aluminum | Compressed air filter material | PE | Seals material | NBR |
| Material of operator panel | PA, POM | Max. Temperature of medium(°C) | 60 | Max. Ambient temperature(°C) | 60 |
| Min. Storage temperature(°C) | -10 | Max. Storage temperature(°C) | 60 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Configure
Basic Attributes
-
Filter, Filtration Level
- 5 μm
- 40µm
-
Bowl guard
- Integrated as metal bowl guard
- Plastic bowl guard
-
Standard nominal flow rate(l/min)
-
Pneumatic connection 1
-
Pneumatic connection 2
-
Material of bowl
- PC
- Wrought aluminum alloy
-
Min. Operating pressure(bar)
- 0.8
- 2
-
Max. Operating pressure(bar)
- 12
- 20
-
Min. Pressure regulation range(bar)
-
Max. Pressure regulation range(bar)
- 7
- 12
-
Min. Temperature of medium(°C)
- -10
- 5
-
Min. Ambient temperature(°C)
- -10
- 5
-
Operating medium
-
Air quality class at the output
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
