Air cylinder standard type single acting / extruded retractable C75 series
[Features]
·Set the part number with mounting support bracket, rod tip bracket, and auto switch
·Contributes to man-hour reduction by saving the trouble of arranging cylinders and metal fittings separately
・ Easy fine adjustment of auto switch position
・ Improved visibility of indicator lamp by making switch bracket transparent
(i)Remark
- ■ SMC Air Cylinder Product Selection and Technical Information
Please check the special page from here.
■About SMC product handling
products without a web page will be released one by one.
If you have a fixed model number, please request a quote / order from here. - Refer to the manufacturer's catalog for specification and material details.
- Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| C75E32-200S |
| C75F32-60T |
| CD75F32-50S-A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Cylinder Operation Method | Stroke: L (mm) | Specifications | Type of Auto Switch Mounting | |
|---|---|---|---|---|---|---|---|---|
97.26 € | 1 | 7 Days | Single Acting (Extruded) | 200 | Without magnet | None | ||
78.45 € | 1 | 7 Days | [Single-Action (Retraction)] Special Single-acting(Retracted by External Force) | 60 | Without magnet | None | ||
81.23 € | 1 | 7 Days | Single Acting (Extruded) | 50 | Built-in magnet | Rail mounting |
Loading...
Basic information
| Rod Operation Method | Single Rods | Main Body Shape | Standard | Cylinder I.D: D(Ø) | 32 |
|---|---|---|---|---|---|
| Additional Function | Standard | Environment, Applications | Standard | End Locking | NA |
| Cushion | Rubber cushion | Support bracket | None | Auto Switch | Without auto switch |
| Lead Wire Length(m) | None | Number of Switches | None | Bellows | None |
| Accessories | N/A |
Configure
Basic Attributes
-
Cylinder Operation Method
- Single Acting (Extruded)
- Single-Action (Retraction)
-
Stroke: L(mm)
-
Specifications
- Built-in magnet
- Without magnet
-
Type of Auto Switch Mounting
- None
- Rail mounting
-
Type
- C75
- CD75
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
