Enamel-coated copper wire
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 1565202 |
| 1567045 |
| 1567046 |
| 1567047 |
| 1567048 |
| 1567049 |
| 1567050 |
| 1570224 |
| 1570225 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Manufacturer part # | Outside diameter (incl. coating) (mm) | |
|---|---|---|---|---|---|---|
7.35 € | 1 | Available | 3 Days | 605604 | 0.80 | |
9.45 € | 1 | Available | 3 Days | 605196 | 0.15 | |
8.40 € | 1 | Available | 3 Days | 605322 | 0.20 | |
7.35 € | 1 | Available | 3 Days | 605426 | 0.30 | |
8.93 € | 1 | Available | 3 Days | 605486 | 0.40 | |
7.35 € | 1 | Available | 3 Days | 605544 | 0.50 | |
7.88 € | 1 | Available | 3 Days | 605660 | 1 | |
9.45 € | 1 | Available | 3 Days | 604975 | 0.05 | |
9.99 € | 1 | Available | 3 Days | 605090 | 0.10 |
Loading...
Basic information
| Type | Wire | Cable features | Enameled | Halogen-free | No |
|---|---|---|---|---|---|
| Material (details) | Electrolytic copper | Max. temperature range (fixed installation)(°C) | +155 | Max. temperature range (flexible installation)(°C) | +155 |
| No. of leads (part 1)(x) | 1 | Packaged | Yes | RoHS-compliant | Yes |
| Sold per metre | No | Type (manufacturer type) | 2 UEWF |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
