High-performance timing belts / OMEGA / 8M / CR / HP (high performance) / OPTIBELT
· For HTD and RPP pulleys
· Profiles 8MHP and 14MHP - Electrically conductive
· Up to two times the power transmission capability of standard OMEGA
· Maintenance-freeFor high loads at various speed
· Abrasion resistant fabric with low friction and shear resistant teeth
· Fiberglass cord
· Improved low-noise characteristics through OMEGA tooth form
· Temperature range -30°C to +100°C
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal width W (mm) (mm) | Customs tariff — weight (kg) | Customs tariff — item number | Number of teeth | Pitch length (mm) | Length (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|
25.05 € | 1 | 5 Days | 20 | 0.12 | 40103500 | 130 | 1.040 | 1.040 | ||
37.66 € | 1 | 5 Days | 30 | 0.18 | 40103500 | 130 | 1.040 | 1.040 | ||
61.86 € | 1 | 5 Days | 50 | 0 | 40103500 | 130 | 1.040 | 1.040 | ||
43.83 € | 1 | 5 Days | 30 | 0.21 | 40103500 | 160 | 1.280 | 1.280 | ||
47.65 € | 1 | 5 Days | 30 | 0.24 | 40103500 | 170 | 1.360 | 1.360 | ||
78.12 € | 1 | 5 Days | 50 | 0 | 40103500 | 175 | 1.400 | 1.400 | ||
51.72 € | 1 | 5 Days | 30 | 0 | 40103600 | 200 | 1.600 | 1.600 | ||
55.45 € | 1 | 5 Days | 30 | 0 | 40103600 | 210 | 1.680 | 1.680 | ||
104.80 € | 1 | 5 Days | 50 | 0.6 | 40103900 | 250 | 2.000 | 2.000 | ||
22.35 € | 1 | 5 Days | 30 | 0 | 40103900 | 60 | 480 | 480 | ||
24.37 € | 1 | 5 Days | 30 | 0.105 | 40103900 | 70 | 560 | 560 | ||
29.14 € | 1 | 5 Days | 30 | 0.15 | 40103500 | 90 | 720 | 720 | ||
31.23 € | 1 | 5 Days | 30 | 0 | 40103500 | 100 | 800 | 800 | ||
35.34 € | 1 | 5 Days | 30 | 0.018 | 40103500 | 120 | 960 | 960 |
Loading...
Basic information
| Temperature resistant from(°C) | -30 | Electrical conductivity yes/no | y | Customs tariff — weight per | 1 |
|---|---|---|---|---|---|
| Customs tariff — weight unit | kg | Acceptance test certificate EN 10204 – 3.1 yes/no | n | Tooth height(mm) | 3.2 |
| Outside idlers can be used yes/no | Yes | Belt thickness(mm) | 5.4 | Profile | 8M |
| Customs tariff — country of origin | DE | Pitch p(mm) | 8 | Engineering material | Polychloroprene |
| Maintenance required | n | Tooth profile | Semi-circular | Oil-resistant | Limited |
| Tension cords | Stronger glass fiber tension cord | Temperature resistant up to(°C) | 100 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
