Shaft holders / block form / slotted / GWH
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| GWH06-B |
| GWH08-B |
| GWH12-B |
| GWH20-B |
| GWH25-B |
| GWH30-B |
| GWH40-B |
| GWH50-B |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | [D] Diameter (mm) | B (mm) | H (mm) | L (mm) | Weight/Unit (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
- | 1 | 4 Days | 6 | 32 | 27 | 16 | 0.03 | |||
- | 1 | 4 Days | 8 | 32 | 27 | 16 | 0.03 | |||
- | 1 | 4 Days | 12 | 40 | 33 | 18 | 0.05 | |||
- | 1 | 4 Days | 20 | 53 | 42.5 | 24 | 0.12 | |||
- | 1 | 4 Days | 25 | 60 | 52.5 | 28 | 0.22 | |||
- | 1 | 4 Days | 30 | 67 | 60 | 30 | 0.22 | |||
- | 1 | 4 Days | 40 | 87 | 73.5 | 40 | 0.48 | |||
- | 1 | 4 Days | 50 | 103 | 92 | 50 | 0.82 |
Loading...
Basic information
| Shape | Block shape | RoHS Certificate | Available | REACH Certificate | Available |
|---|
Configure
Basic Attributes
-
[D] Diameter(mm)
-
B(mm)
-
H(mm)
-
L(mm)
-
Weight/Unit(kg)
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
