Flange Bearing Unit, Food-Line, ConCentra
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| FYNT 35 L |
| FYNT 50 F |
| FYNT 50 L |
| FYNT 60 F |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Bore Dia. d (mm) | GTIN/EAN | Series | Storage | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|
280.52 € | 1 | Quote | 35 | 7316574363735 | FYNT…L | floating bearing | 2600 | ||
444.72 € | 1 | Quote | 50 | 7316574500451 | FYNT…F | fixed bearing | 4600 | ||
444.72 € | 1 | Quote | 50 | 7316574500468 | FYNT…L | floating bearing | 4600 | ||
513.92 € | 1 | 12 Days | 60 | 7316574500505 | FYNT…F | fixed bearing | 6900 |
Loading...
Basic information
| Mounting tensioning bearing | ConCentra-step sleeve | Type of mounting holes | thread | Sealing | double lip seal |
|---|---|---|---|---|---|
| Case material | grey cast iron | Seal material | NBR/steel plate | Thread size | M12 |
| Customs tariff number | 84832000 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
