Wiper-rod Seal, 85AU20991
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 468060 |
| 468061 |
| 468065 |
| 468066 |
| 468120 |
| 470526 |
| 471728 |
| 476708 |
| 476906 |
| 49067732 |
| 49067733 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Outer Diameter (mm) | Internal Diameter (φ) | Groove length (mm) | Width (mm) | Series | Customs tariff number | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
10.19 € | 1 | Available | 7 Days | 16.5 | 12 | 3.6 | 3.6 | NIPSL 310 | 84129080 | 0.331 | |
10.19 € | 1 | Available | 7 Days | 14 | 10 | 3.2 | 3.2 | NIPSL 310 | 84129080 | 0.221 | |
10.19 € | 1 | Available | 17 Days | 11.5 | 8 | 2.9 | 2.5 | NIPSL 310 | 84129080 | 0.141 | |
9.85 € | 1 | Available | 7 Days | 9 | 6 | 2.6 | 2.2 | NIPSL 310 | 84129080 | 0.116 | |
11.22 € | 1 | Available | 12 Days | 20.5 | 16 | 3.6 | 3.2 | NIPSL 310 | 84129080 | 0.421 | |
11.22 € | 1 | Available | 7 Days | 25 | 20 | 4 | 4 | NIPSL 310 | 84129080 | 0.7 | |
12.26 € | 1 | Available | 12 Days | 30 | 25 | 4 | 3.6 | NIPSL 310 | 84129080 | 0.791 | |
10.19 € | 1 | Available | 12 Days | 7 | 4 | 2.6 | 2.2 | NIPSL 310 | 84129080 | 0.061 | |
15.90 € | 1 | Available | 12 Days | 37.5 | 32 | 4.4 | 4.4 | NIPSL 310 | 84129080 | 1.121 | |
11.22 € | 1 | Available | 7 Days | 18.1 | 12 | - | 3.8 | NIPSL 300 | 39269097 | 0.66 | |
11.22 € | 1 | Available | 17 Days | 23 | 16 | - | 6.2 | NIPSL 300 | 39269097 | 2 |
Loading...
Basic information
| Hardness in Shore | 85 | Material | 85AU20991 |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
