D3000 Series Tool
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 91558-1 |
| 91559-1 |
| 91560-1 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Applicable parts | Applicable wire range (AWG) | Applicable wire range (mm2) | Insulation coating outer diameter (mm) | Contact wire range mark | |
|---|---|---|---|---|---|---|---|---|---|
1,002.18 € | 1 | 5 Days | 1-175218-5 / 1-175218-3 / 1-175218-2 / 175218-3 / 175218-2 / 175289-5 / 175289-3 / 175289-2 | 20 to 16 | 0.5 to 1.25 | 1.8 to 2.8 / 2.2 to 2.8 | L | ||
822.38 € | 1 | 5 Days | 1-175217-5 / 1-175217-2 / 1-75217-3 / 175217-3 / 175217-2 / 175288-5 / 175288-3 / 175288-2 | 24 to 20 | 0.2–0.5 | 1.7 to 2.6 | M | ||
838.78 € | 1 | 5 Days | 1-917511-5 / 1-917511-3 / 1-917511-2 / 917511-3 / 917511-2 / 917512-5 / 917512-3 / 917512-2 | 16 to 14 | 1.25 to 2.2 | 2.2 to 2.8 | 2L |
Loading...
Basic information
| Applicable Type | For Bulk | Applicable Series | D3000 Series | Applicable Series | D3000 series |
|---|---|---|---|---|---|
| Applicable Type | For individuals | Contact Type | Reseller / Tab | Type | Manual Tool |
Configure
Basic Attributes
-
Applicable parts
-
Applicable wire range(AWG)
-
Applicable wire range(mm2)
- 0.2–0.5
- 0.5 to 1.25
- 1.25 to 2.2
-
Insulation coating outer diameter(mm)
- 1.7 to 2.6
- 1.8 to 2.8
- 2.2 to 2.8
-
Contact wire range mark
- 2L
- L
- M
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
