Insulok lock PEEK tie super heat resistant grade【100 Pieces Per Package】
- Volume Discount
Insulok tie with super heat resistance up to 240°C (up to 260°C for the UL temperature index of raw materials). One particular appeal of this product is its particularly low degree of outgassing.
[Features]
· Insulok tie standard product.
High environmentally resistant properties, and even when metal wiring material is not used the plastic resin characteristics make flexible binding work possible.
· The low generation of gas means it is effective when used in outgassing countermeasures.
· PT2A: Because the serration (the jagged parts on the strap surface) is on the outside, it should be used for wires with thin coats.
· PT220 type: The bundle diameter is larger than for PT2A and has a high tensile strength.
· Inside serration, as with the normal Insulok type.
[Features]
· Insulok tie standard product.
High environmentally resistant properties, and even when metal wiring material is not used the plastic resin characteristics make flexible binding work possible.
· The low generation of gas means it is effective when used in outgassing countermeasures.
· PT2A: Because the serration (the jagged parts on the strap surface) is on the outside, it should be used for wires with thin coats.
· PT220 type: The bundle diameter is larger than for PT2A and has a high tensile strength.
· Inside serration, as with the normal Insulok type.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| PT2A |
| PT220 |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | RoHS | Band Diameter (mm) | Overall Length L (mm) | Width A (mm) | UL flame retardant grade (main raw material) | Loop tensile strength (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
252.67 € | 100 Pieces Per Package | 1 pack | Available | 5 Days | 10 | 4 to 35 | 145 | 3.4 | UL94V-0 | 230 | |
340.50 € | 100 Pieces Per Package | 1 pack | Available | 5 Days | 10 | 8 to 56 | 220 | 4.7 | N/A | 380 |
Loading...
Basic information
| Material | PEEK | Color | Beige | Grade | Heat Resistant / Chemical-Resistant |
|---|---|---|---|---|---|
| Number with packs(Book) | 100 | Operating Temperature Range (Min)(°C) | -55 | Operating Temperature Range (Max)(°C) | 240 |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
