This offset Insulok push-mounting tie includes wings and is available in heat resistant and weatherproof grades.【100 Pieces Per Package】
- Volume Discount
Type with wings. Can be used in high temperatures and outdoor environments.
[Features]
· Use to attach wires to chassis, panels, walls, etc.
· Offset type, with wings.
· The support wings are spread out and secured to the installed panel surface.
· High stability after securing.
· A push-mount tie with wings.
· Can be securely fixed in the installation hole.
[Features]
· Use to attach wires to chassis, panels, walls, etc.
· Offset type, with wings.
· The support wings are spread out and secured to the installed panel surface.
· High stability after securing.
· A push-mount tie with wings.
· Can be securely fixed in the installation hole.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
RT18RSF-HSW
Basic information
| Band Diameter(mm) | 1.0 to 27 | Overall Length L(mm) | 132 | Width A(mm) | 3 |
|---|---|---|---|---|---|
| Material | Nylon 66 | Color | Black | Grade | Weather-Resistant / Heat Resistant |
| UL flame retardant grade (main raw material) | UL94V-2 | Special Function/Application | Reusable type / Push mount | Standard | UL standard certified product |
| Number with packs(Book) | 100 | Loop tensile strength(N) | 80 | Mounting hole ∅(mm) | 3.8 to 4.2 |
| Maximum Mounting Panel Thickness(mm) | 2.3 | Operating Temperature Range (Min)(°C) | -40 | Operating Temperature Range (Max)(°C) | 110 |
This page is This offset Insulok push-mounting tie includes wings and is available in heat resistant and weatherproof grades., part number RT18RSF-HSW.
You can find the detail information about specifications and dimensions on part number RT18RSF-HSW.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
