Trusco Insertion-Type Pin Terminal With Insulated Coating【15 Pieces Per Package】
· Wire connections and relays can be added and removed in a single action.
[Applications]
· Allows for the mating of wire connections and relays inside equipment by combining male (M) and female (F) sides.
[Specifications]
Compatible tools: Tools for crimp terminals with insulated coating and for sleeves.
· Rated voltage: 300 V.
[Materials]
· Terminal: Brass (C2680) / tin electroplating.
· Insulator: Nylon.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| TPC2005F |
| TPC4009F |
| TPC4009M |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Overall Length (mm) | Conforming wire size (AWG) | Insulation coating (color) | Wire conjugation stranded cable (mm2) | External Dimensions (mm) | Inside Dimension (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
14.58 € | 15 Pieces Per Package | 1 pack | 6 Days | 24.5 | 20-18 | Transparency | 0.50 to 0.75 | 4.6 | 1.7 | ||
14.58 € | 15 Pieces Per Package | 1 pack | 6 Days | 26.2 | 18-16 | Red | 0.75 to 1.25 | 6.9 | 1.8 | ||
9.67 € | 15 Pieces Per Package | 1 pack | 6 Days | 27.7 | 20-18 | Transparency | 0.50 to 0.75 | 7.4 | 1.8 |
Loading...
Basic information
| Type | Insertion Type Connector | Rated Voltage(V) | 300 | Material 1 | Terminal: Brass (C2680) / tin electroplating |
|---|---|---|---|---|---|
| Materials 2 | Insulator: Nylon | Conforming tools | Tools for crimp terminals with insulated coating and for sleeves |
Configure
Basic Attributes
-
Overall Length(mm)
-
Conforming wire size(AWG)
-
Insulation coating (color)
- Red
- Transparency
-
Wire conjugation stranded cable(mm2)
-
External Dimensions(mm)
-
Inside Dimension(mm)
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
