Blade Receptacle + Branch Joint
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1730AZ |
| 18203AZ |
| 18303AZ |
| 720AZ |
| 720V |
| 730AZ |
| 730V |
| 750AZ |
| 750V |
| 8201V |
| 8203V |
| 8301AV |
| 8301V |
| 8302V |
| 8303V |
| 8503V |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Colour | Connector features | Connector thickness (mm) | Connector width (mm) | Cross-section range | Cross section (mm²) | Cross section (max.) (mm²) | Insulation type | Insulation material | Insulation (material) | Manufacturer part # | Material (details) | Min. cross section (mm²) | Size | Type (manufacturer type) | Type (misc.) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0.51 € | 1 | Available | 3 Days | Metal | + branch joint | 0.8 | 6.3 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Not insulated | - | - | 1730AZ | CuZn. tin-plated | 1.5 | 6.3 x 0.8 mm | 1730AZ | 6.3 x 0.8 mm | |
0.47 € | 1 | Available | 3 Days | Metal | + branch joint | 0.8 | 4.8 | 0.50 - 1 mm² | 0.5 - 1 | 1 | Not insulated | - | - | 18203AZ | CuZn. tin-plated | 0.5 | 4.8 x 0.8 mm | 18203AZ | 4.8 x 0.8 mm | |
0.47 € | 1 | Available | 3 Days | Metal | + branch joint | 0.8 | 4.8 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Not insulated | - | - | 18303AZ | CuZn. tin-plated | 1.5 | 4.8 x 0.8 mm | 18303AZ | 4.8 x 0.8 mm | |
0.52 € | 1 | Available | 3 Days | Red | + branch joint | 0.8 | 6.3 | 0.50 - 1 mm² | 0.5 - 1 | 1 | Partially insulated | PVC | PVC | 720AZ | CuZN. tin-plated | 0.5 | 6.3 x 0.8 mm | 720AZ | 6.3 x 0.8 mm | |
0.48 € | 1 | Available | 3 Days | Red | - | 0.8 | 6.3 | 0.50 - 1 mm² | 0.5 - 1 | 1 | Insulated | PVC | PVC | 720V | CuZn. tin-plated | 0.5 | 6.3 x 0.8 mm | 720V | 6.3 x 0.8 mm | |
0.53 € | 1 | Available | 3 Days | Blue | + branch joint | 0.8 | 6.3 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Partially insulated | PVC | PVC | 730AZ | CuZN. tin-plated | 1.5 | 6.3 x 0.8 mm | 730AZ | 6.3 x 0.8 mm | |
0.49 € | 1 | Available | 3 Days | Blue | - | 0.8 | 6.3 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Insulated | PVC | PVC | 730V | CuZn. tin-plated | 1.5 | 6.3 x 0.8 mm | 730V | 6.3 x 0.8 mm | |
0.75 € | 1 | Available | 3 Days | Yellow | + branch joint | 0.8 | 6.3 | 4 - 6 mm² | 4 - 6 | 6 | Partially insulated | PVC | PVC | 750AZ | CuZN. tin-plated | 4 | 6.3 x 0.8 mm | 750AZ | 6.3 x 0.8 mm | |
0.60 € | 1 | Available | 3 Days | Yellow | - | 0.8 | 6.3 | 4 - 6 mm² | 4 - 6 | 6 | Insulated | PVC | PVC | 750V | CuZn. tin-plated | 4 | 6.3 x 0.8 mm | 750V | 6.3 x 0.8 mm | |
0.75 € | 1 | Available | 3 Days | Red | - | 0.5 | 2.8 | 0.50 - 1 mm² | 0.5 - 1 | 1 | Insulated | Polyamide 6.6 | Halogen-free PA | 8201V | CuZn. tin-plated | 0.5 | 2.8 x 0.5 mm | 8201V | 2.8 x 0.5 mm | |
0.73 € | 1 | Available | 16 Days | Red | - | 0.8 | 4.8 | 0.50 - 1 mm² | 0.5 - 1 | 1 | Insulated | PVC | PVC | 8203V | CuZn. tin-plated | 0.5 | 4.8 x 0.8 mm | 8203V | 4.8 x 0.8 mm | |
0.75 € | 1 | Available | 3 Days | Blue | - | 0.8 | 2.8 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Insulated | PVC | PVC | 8301AV | CuZn. tin-plated | 1.5 | 2.8 x 0.8 mm | 8301AV | 2.8 x 0.8 mm | |
0.73 € | 1 | Available | 3 Days | Blue | - | 0.5 | 2.8 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Insulated | PVC | PVC | 8301V | CuZn. tin-plated | 1.5 | 2.8 x 0.5 mm | 8301V | 2.8 x 0.5 mm | |
0.75 € | 1 | Available | 3 Days | Blue | - | 0.5 | 4.8 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Insulated | PVC | PVC | 8302V | CuZn. tin-plated | 1.5 | 4.8 x 0.5 mm | 8302V | 4.8 x 0.5 mm | |
0.73 € | 1 | Available | 3 Days | Blue | - | 0.8 | 4.8 | 1.50 - 2.50 mm² | 1.5 - 2.5 | 2.5 | Insulated | PVC | PVC | 8303V | CuZn. tin-plated | 1.5 | 4.8 x 0.8 mm | 8303V | 4.8 x 0.8 mm | |
0.79 € | 1 | Available | 3 Days | Yellow | - | 0.8 | 4.8 | 4 - 6 mm² | 4 - 6 | 6 | Insulated | PVC | PVC | 8503V | CuZn. tin-plated | 4 | 4.8 x 0.8 mm | 8503V | 4.8 x 0.8 mm |
Loading...
Basic information
| Connection angle(°) | 180 | Contact material | Brass tin plated | Product type | Blade receptacle |
|---|
Configure
Basic Attributes
-
Colour
-
Connector features
-
Connector thickness(mm)
-
Connector width(mm)
-
Cross-section range
-
Cross section(mm²)
-
Cross section (max.)(mm²)
-
Insulation type
-
Insulation material
-
Insulation (material)
-
Manufacturer part #
-
Material (details)
-
Min. cross section(mm²)
-
Size
-
Type (manufacturer type)
-
Type (misc.)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 16 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
