Klauke 8503B Blade terminal Connector width: 4.8 mm Connector thickness: 0
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
8503B
Basic information
| Colour | Yellow | Connection angle(°) | 180 | Connector thickness(mm) | 0.8 |
|---|---|---|---|---|---|
| Connector width(mm) | 4.8 | Contact material | Brass tin plated | Cross-section range | 4 - 6 mm² |
| Cross section(mm²) | 4 - 6 | Cross section (max.)(mm²) | 6 | Insulation type | Partially insulated |
| Insulation material | PA 6.6 | Insulation (material) | Halogen-free PA | Manufacturer part # | 8503B |
| Material (details) | CuZn. tin-plated | Min. cross section(mm²) | 4 | Product type | Blade terminal |
| Size | 4.8 x 0.8 mm | Support sleeve | No | Type (manufacturer type) | 8503B |
| Type (misc.) | 4.8 x 0.8 mm |
This page is Klauke 8503B Blade terminal Connector width: 4.8 mm Connector thickness: 0, part number 8503B.
You can find the detail information about specifications and dimensions on part number 8503B.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
