Klauke 704 Pin terminal 0.10 mm² 0.40 mm² Partially insulated Yellow 1 pc(
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
704
Basic information
| Colour | Yellow | Contact material | Cathode copper. tin plated | Cross-section range | 0.10 - 0.40 mm² |
|---|---|---|---|---|---|
| Cross section(mm²) | 0.1 - 0.4 | Cross section (max.)(mm²) | 0.40 | Insulation type | Partially insulated |
| Insulation material | PA | Insulation (material) | PA. | Manufacturer part # | 704 |
| Material (details) | Cu-ETP. tin-plated | Min. cross section(mm²) | 0.10 | Product type | Pin terminal |
| Support sleeve | No | Type (manufacturer type) | 704 | Pin diameter(mm) | 1.4 |
| Temperature range(°C) | +105 | Crimp area (max.)(mm²) | 0.40 | Pin length(mm) | 9|9 |
This page is Klauke 704 Pin terminal 0.10 mm² 0.40 mm² Partially insulated Yellow 1 pc(, part number 704.
You can find the detail information about specifications and dimensions on part number 704.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
