HEAVYCON male insert, HC-B24
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
1605666
Basic information
| Width(mm) | - | Height(mm) | - | Depth(mm) | - |
|---|---|---|---|---|---|
| Rated voltage(V) | 500 | With wire protection | false | Number of poles | 24 |
| Contact type | Pin | Ambient temperature(°C) | -40|125 | Operation temperature(°C) | -|- |
| Inflammability class of insulation material acc. with UL94 | V0 | Rated surge voltage(kV) | 6 | Type of electric connection | Insulation displacement connection |
| Material of contact surface | Other | Over voltage category | III | Pollution degree | 3 |
| Diameter plug-in contact(mm) | 2.5 | Contact insert without contacts | false | Connectable conductor cross section solid-core(mm²) | 0.34|2.5 |
| Connectable conductor cross section fine-strand with cable end sleeve(mm²) | 0.34|2.5 | Connectable conductor cross section fine-strand without cable end sleeve(mm²) | 0.34|2.5 | Connectable conductor cross section multi-wired(mm²) | -|- |
| With protective conductor | true | Material contact | Other copper alloys | Material connector of connector insert | Thermoplastic |
| Rated current In(A) | 16 | Material of contact insert | - | Min. number of insertion cycles | - |
| Number of power contacts | - | Number of control contacts | - |
This page is HEAVYCON male insert, HC-B24, part number 1605666.
You can find the detail information about specifications and dimensions on part number 1605666.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
