Power Wrench
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 4-50N |
| 6-100N |
| 6-150N |
| 8-300N |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Output angle (mm) | Output torque range (N▪m) | Input Torque Range (N▪m) | Mass (g) | |
|---|---|---|---|---|---|---|---|---|
596.11 € | 1 | 5 Days | 12.7 | 420 | 140 | 1500 | ||
664.06 € | 1 | 9 Days | 19 | 850 | 283 | 2500 | ||
859.44 € | 1 | 8 Days | 19 | 1200 | 400 | 3600 | ||
1,093.07 € | 1 | 9 Days | 25.4 | 2550 | 850 | 7200 |
Loading...
Basic information
| Product Type | Other | Load direction | Left/Right | Set / Single Item | Set Product |
|---|---|---|---|---|---|
| Magnification | Approx. 3x Magnification | Main body: option | Main Body | Supplementary explanation | Output torque = Input torque x Wrench magnification (3 times) |
Configure
Basic Attributes
-
Output angle(mm)
- 12.7
- 19
- 25.4
-
Output torque range(N▪m)
-
Input Torque Range(N▪m)
-
Mass(g)
-
Type
- 4-50N-8-300N
Filter by standard shipping days
-
- All
- 5 Days or Less
- 8 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
