Flower Type Brush, Steel
- Because the brush is facing the side, it enables focus polishing of only the hole intersecting the blind hole.
- Enables lateral polishing.
- It is a cushioned brush so that the bottom of the blind hole can be reached.
[Applications]
- Ideal for deburring intersecting holes at each bottom location from the cylinder inner diameter opening.
- Removing dirt and rust from various metals, cleaning before and after the welding process.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 20SF-6 |
| 20WF-6 |
| 25SF-6 |
| 25WF-6 |
| 30SF-6 |
| 30WF-6 |
| 35SF-6 |
| 35WF-6 |
| 40SF-6 |
| 40WF-6 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Outer Diameter (mm) | Details Type | Shaft length (mm) | Hair material | Trusco Code | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|
24.07 € | 1 | 6 Days | 20 | Stainless Steel | 25 | Stainless Steel | 415-2590 | 40 | ||
20.53 € | 1 | 6 Days | 20 | Steel Wire | 25 | Steel Wire | 415-2603 | 40 | ||
24.07 € | 1 | 6 Days | 25 | Stainless Steel | 25 | Stainless Steel | 415-2611 | 40 | ||
20.53 € | 1 | 6 Days | 25 | Steel Wire | 25 | Steel Wire | 415-2620 | 40 | ||
27.16 € | 1 | 6 Days | 30 | Stainless Steel | 35 | Stainless Steel | 415-2638 | 75 | ||
23.36 € | 3 | 6 Days | 30 | Steel Wire | 35 | Steel Wire | 415-2646 | 75 | ||
27.19 € | 1 | 6 Days | 35 | Stainless Steel | 35 | Stainless Steel | 415-2654 | 80 | ||
23.39 € | 3 | 6 Days | 35 | Steel Wire | 35 | Steel Wire | 415-2662 | 80 | ||
36.18 € | 1 | 6 Days | 40 | Stainless Steel | 35 | Stainless Steel | 415-2671 | 135 | ||
29.12 € | 1 | 6 Days | 40 | Steel Wire | 35 | Steel Wire | 415-2689 | 135 |
Loading...
Basic information
| Product Type | Flower Type Brush | Wire diameter(mm) | 0.3 | Shaft Diameter(mm) | 6 |
|---|---|---|---|---|---|
| Hair length(mm) | 10 | Max. Rotational Speed(rpm) | 3000 | Features | Can selectively polish only the cross holes in the blind holes, since the brush is facing the side. |
| Application | Ideal for deburring cross holes from cylinder bore entrance to bottoms. |
Configure
Basic Attributes
-
Outer Diameter(mm)
-
Details Type
- Stainless Steel
- Steel Wire
-
Shaft length(mm)
- 25
- 35
-
Hair material
-
Trusco Code
-
Type
- F-6
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
