Electrodeposition Diamond Tool for Grinding Centering, Seratap, ED-PNT
-The tool attached to the pilot hole shaft performs a self-rotating and orbital motion to grind a thread with a pitch.
-The X, Y and Z axes are fed simultaneously, so the requirement for use is that the machine is equipped with a 3-axis simultaneous control mechanism.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| ED-PNT-2.2X7.5XP0.5-#600 |
| ED-PNT-3X9.8XP0.7-#400 |
| ED-PNT-3.7X12XP0.8-#400 |
| ED-PNT-4.5X15XP1-#400 |
| ED-PNT-6X20XP1.25-#400 |
| ED-PNT-7.5X24XP1.5-#400 |
| ED-PNT-9X30XP1.75-#400 |
| ED-PNT-10X34XP2-#400 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Pitch, Number of Threading (mm) | L (mm) | Outer Diameter (mm) | Length under neck (mm) | Shank diameter (mm) | Thread Length (mm) | Electrodeposition length (mm) | Minimum Machining Diameter (mm) | Particle Size (#) | Tool No. | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
115.92 € | 1 | 6 Days | 0.5 | 50 | 2.2 | 8.5 | 4 | 7.5 | 8.5 | 3 | 600 | 8315981 | ||
121.88 € | 1 | 6 Days | 0.7 | 60 | 3 | 12 | 6 | 9.8 | 12 | 4 | 400 | 8315982 | ||
126.21 € | 1 | 6 Days | 0.8 | 60 | 3.7 | 14 | 6 | 12 | 14 | 5 | 400 | 8315983 | ||
133.25 € | 1 | 6 Days | 1 | 70 | 4.5 | 18 | 8 | 15 | 18 | 6 | 400 | 8315984 | ||
138.67 € | 1 | 6 Days | 1.25 | 70 | 6 | 23 | 8 | 20 | 23 | 8 | 400 | 8315985 | ||
164.67 € | 1 | 6 Days | 1.5 | 80 | 7.5 | 27 | 10 | 24 | 27 | 10 | 400 | 8315986 | ||
177.12 € | 1 | 6 Days | 1.75 | 80 | 9 | 33 | 10 | 29.8 | 33 | 12 | 400 | 8315987 | ||
209.08 € | 1 | 6 Days | 2 | 80 | 10 | 39 | 10 | 34 | 39 | 14 | 400 | 8315988 |
