Electronics Nippers 7752-115
Optimal high-precision nippers for extremely precise electronics-related, and precision equipment-related cutting work.
[Features]
· Three-piece combination joint (box joint).
· The double open spring reduces resistance so that the mouth doesn't have to be opened over and over during repetitious work.
· Style: Flat tapered head, cutting surface is shaped like a small umbrella.
· Head finish: Mirror finish.
· Handle Specification: Comfort
[Features]
· Three-piece combination joint (box joint).
· The double open spring reduces resistance so that the mouth doesn't have to be opened over and over during repetitious work.
· Style: Flat tapered head, cutting surface is shaped like a small umbrella.
· Head finish: Mirror finish.
· Handle Specification: Comfort
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
7752-115
Basic information
| Product Category | Nippers | Nipper Type | Nippers | Overall Length(mm) | 115 |
|---|---|---|---|---|---|
| With or without Spring | Available | Single Product/Set Classification | Single Item | Mass(g) | 80 |
| Soft Wire Cutting Performance(φ/mm) | 0.3-1 | Medium-hard Wire Cutting Capability(φ/mm) | 0.8 | Hard Wire Cutting Performance(φ/mm) | 0.5 |
| Main body: option | Main Body | JAN Code | 4003773040750 | Specifications | Head Finish: Mirror Finish / Handle Specification: Comfort / Style: Flat Tapered Head |
| Features | The three-piece combination joint (box joint) and low-resistance dual-spring opening enable repeated work to be conducted without opening the mouth. The blade hardness is approximately HRC 57 and it is made of special oil hardened and tempered special tool steel. It has been subjected to head finishing type 2, which is a polishing processing with high-grade oil that prevents rust and keeps the circuit from being adversely affected if the plating peels off of the tool. | Notes | * Comfort handle (main item) is not insulated. |
This page is Electronics Nippers 7752-115, part number 7752-115.
You can find the detail information about specifications and dimensions on part number 7752-115.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
