Hand Socket 3 / 8" "(9.5 mm) Hex Extra Deep Socket 3300M(L120)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3300M-8-L120 |
| 3300M-10-L120 |
| 3300M-12-L120 |
| 3300M-14-L120 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width across flat dimension | Dimension d1 (mm) | Dimension D2 (mm) | Dimension L (mm) | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|
38.84 € | 1 | 6 Days | 8 | 12 | 17.3 | 9 | 85 | ||
36.13 € | 1 | 9 Days | 10 | 14.5 | 17.3 | 11 | 110 | ||
36.18 € | 1 | 6 Days | 12 | 16.8 | 17.2 | 13 | 116 | ||
43.74 € | 1 | 6 Days | 14 | 20 | 18 | 16 | 166 |
Loading...
Basic information
| Single Product/Set Classification | Single Item Socket | Application | For handwork | Insertion Angle (Shaft measurement when electric drill) (mm) | 9.5 |
|---|---|---|---|---|---|
| Socket shape | 6 Sq. | Insertion Angle (Shaft measurement when electric drill) (Inch) | 3/8 | Overall length (L dimension)(mm) | 120 |
| Dimension H(mm) | 106.5 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
