Connecting plates / bore selectable
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Loading...
Part Number
|
|---|
| DKP200-F[95-150/5] |
| DKP250-F[145-200/5] |
| DKP300-F[195-250/5] |
| DKPL200-F[120-150/5] |
| DKPL250-F[170-200/5] |
| DKPL300-F[220-250/5] |
| DKPL350-F[270-300/5] |
| DKPL400-F[320-350/5] |
| Part Number | Minimum order quantity | Volume Discount | RoHS | Hole specifications | L (L dimension) (mm) | F (Hole pitch) (mm) | |
|---|---|---|---|---|---|---|---|
| 1 | Quote | 10 | Round holes on both sides | 200 | 95 ～ 150 | ||
| 1 | Quote | 10 | Round holes on both sides | 250 | 145 ～ 200 | ||
| 1 | Quote | 10 | Round holes on both sides | 300 | 195 ～ 250 | ||
| 1 | Quote | 10 | Slotted hole on one side | 200 | 120 ～ 150 | ||
| 1 | Quote | 10 | Slotted hole on one side | 250 | 170 ～ 200 | ||
| 1 | Quote | 10 | Slotted hole on one side | 300 | 220 ～ 250 | ||
| 1 | Quote | 10 | Slotted hole on one side | 350 | 270 ～ 300 | ||
| 1 | Quote | 10 | Slotted hole on one side | 400 | 320 ～ 350 |
Loading...
Configure
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
