Precision Small Diameter·Thin-Wall Stepped Ejector Sleeves -SKH51/Concentricity0.005/0.3mm Wall Type-

Precision Small Diameter·Thin-Wall Stepped Ejector Sleeves -SKH51/Concentricity0.005/0.3mm Wall Type-

Click on this image to zoom in.

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
ESVF2.5-[40-70/0.01]-P[1.8-2.5/0.01]-V[0.8-1.6/0.01]-N[20-60/1]-S[1-4.5/0.5]
ESVF3-[40-125/0.01]-P[1.8-2.95/0.01]-V[0.8-2.1/0.01]-N[20-115/1]-S[1-6/0.5]
ESVF3.5-[40-125/0.01]-P[1.8-3.45/0.01]-V[0.8-2.6/0.01]-N[20-115/1]-S[1-7.5/0.5]
ESVF4-[40-125/0.01]-P[1.9-3.95/0.01]-V[0.8-3.1/0.01]-N[20-115/1]-S[1-9/0.5]
ESVF4.5-[40-125/0.01]-P[2.65-4.45/0.01]-V[1.1-3.6/0.01]-N[20-115/1]-S[1-10.5/0.5]
ESVF5-[40-125/0.01]-P[2.65-4.95/0.01]-V[1.2-4.1/0.01]-N[20-115/1]-S[1-12/0.5]
ESVF5.5-[40-125/0.01]-P[2.65-5.45/0.01]-V[1.2-4.6/0.01]-N[20-115/1]-S[1-13.5/0.5]
ESVF6-[40-150/0.01]-P[2.9-5.95/0.01]-V[1.6-5.1/0.01]-N[20-140/1]-S[1-15/0.5]
Part NumberVolume DiscountShipping Days?RoHSD (Shaft diameter)
(mm)
P (Tip diameter)
(mm)
V (Hole diameter)
(mm)
L (L dimension)
(mm)
N
(mm)
S (V hole diameter length)
(mm)
Quote 102.51.8 ~ 2.50.8 ~ 1.640 ~ 7020 ~ 601 ~ 4.5
Quote 1031.8 ~ 2.950.8 ~ 2.140 ~ 12520 ~ 1151 ~ 6
Quote 103.51.8 ~ 3.450.8 ~ 2.640 ~ 12520 ~ 1151 ~ 7.5
Quote 1041.9 ~ 3.950.8 ~ 3.140 ~ 12520 ~ 1151 ~ 9
Quote 104.52.65 ~ 4.451.1 ~ 3.640 ~ 12520 ~ 1151 ~ 10.5
Quote 1052.65 ~ 4.951.2 ~ 4.140 ~ 12520 ~ 1151 ~ 12
Quote 105.52.65 ~ 5.451.2 ~ 4.640 ~ 12520 ~ 1151 ~ 13.5
Quote 1062.9 ~ 5.951.6 ~ 5.140 ~ 15020 ~ 1401 ~ 15

Loading...

  1. 1

Basic information

Product composition Single sleeve Material SKH51 Surface treatment No
Head thickness 4mm(T4) Concentricity ◎0.005 Boring method Grinding
Inner dia. tolerance +0.005/0 Tapered or not No Shaft diameter tolerance 0/-0.005
