Suction Cups / Soft / Soft Bellows
Click on this image to zoom in.
Click on this image to zoom in.
- Volume Discount
(i)Remark
- Set includes pads, adaptors and gaskets.
- The surface that does not come into contact with the workpiece on VPCE is engraved for material identification.
(Sequentially for deliveries from October 2023. Both engraved and non-engraved products will be mixed during the inventory turnover period.) - The inner diameter of the VPDT6 has been changed from ø2.2 to ø2.5.
- Please check the content on our website as the PDF does not contain the most up-to-date information.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
 | Adaptor・Gasket
|
| Type | [ M ]Material | Pad Shape | [ M ]Hardness | Color |
| VPCT | Nitrile Rubber | Soft | Shore A40 ~ 45 | Black |
| VPCE | Conductive Silicon Rubber | Shore A60 | Black | |
| VPDT | Nitrile Rubber | Soft Bellows | Shore A40 ~ 45 | Black |
Specifications
| Part Number |
| MVCKN4 |
| VPDT10 |
| Part Number | Applicable Vacuum Fitting MVC□ | Mounting | VPCT | VPCE | |||
| Unit Price | Volume Discount Rate | Unit Price | Volume Discount Rate | ||||
| Type | No. | 1 ~ 9 pc(s). | 10~30 | 1 ~ 9 pc(s). | 10~30 | ||
| VPCT VPCE | 4 | 4 | Attachment Type | ||||
| 6 | 6 | ||||||
| 8 | 8 | ||||||
| 10 | 10 | ||||||
| 15 | 15 | ||||||
| Part Number | Applicable Vacuum Fitting MVD□ | Mounting | Unit Price | Volume Discount Rate | |
| Type | No. | 1 ~ 9 pc(s). | 10~30 | ||
| VPDT | 6 | 6 | Attachment Type | ||
| 8 | 8 | ||||
| 10 | 10 | ||||
| 15 | 15 | ||||
Part Number:
- In order to open the 3D preview, the part number must be fixed.
3D preview is not available, because the part number has not yet been determined.
Part Number
|
|---|
| VPCE4 |
| VPCE6 |
| VPCE8 |
| VPCE10 |
| VPCE15 |
| VPCT4 |
| VPCT6 |
| VPCT8 |
| VPCT10 |
| VPCT15 |
| VPDT6 |
| VPDT8 |
| VPDT10 |
| VPDT15 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Pad Type | Rubber Group Material | Usage Environment | Heat Resistance Temperature, Max. Operating Temperature, Min. Operating Temperature (°C) | O.D. (d) (Ø) | |
|---|---|---|---|---|---|---|---|---|---|---|
4.15 € | 1 | Available | 5 Days | 10 | Soft | [Silicone Rubber] Conductive Silicon Rubber | Standard / Static Diffusion | -40～180 | 4 | |
4.15 € | 1 | Available | 5 Days | 10 | Soft | [Silicone Rubber] Conductive Silicon Rubber | Standard / Static Diffusion | -40～180 | 6 | |
4.15 € | 1 | Available | 5 Days | 10 | Soft | [Silicone Rubber] Conductive Silicon Rubber | Standard / Static Diffusion | -40～180 | 8 | |
4.15 € | 1 | Available | 5 Days | 10 | Soft | [Silicone Rubber] Conductive Silicon Rubber | Standard / Static Diffusion | -40～180 | 10 | |
4.64 € | 1 | Available | 5 Days | 10 | Soft | [Silicone Rubber] Conductive Silicon Rubber | Standard / Static Diffusion | -40～180 | 15 | |
2.93 € | 1 | Available | 5 Days | 10 | Soft | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 4 | |
2.93 € | 1 | Available | 5 Days | 10 | Soft | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 6 | |
2.93 € | 1 | Available | 5 Days | 10 | Soft | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 8 | |
2.93 € | 1 | Available | 5 Days | 10 | Soft | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 10 | |
3.43 € | 1 | Available | 5 Days | 10 | Soft | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 15 | |
4.15 € | 1 | Available |
Same day
Stock | 10 | Soft Bellows | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 6 | |
4.15 € | 1 | Available | 5 Days | 10 | Soft Bellows | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 8 | |
4.15 € | 1 | Available | 5 Days | 10 | Soft Bellows | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 10 | |
4.64 € | 1 | Available | 5 Days | 10 | Soft Bellows | [Nitrile Rubber] Nitrile Rubber | Standard / Oil Resistance | -30～110 | 15 |
Loading...
More Information
Example of Use
Basic information
| Pad type | Pad Only | Mounting Type | Attachment Type | Material | Rubber Group |
|---|---|---|---|---|---|
| Color | Black |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Pad Type
- Soft
- Soft Bellows
-
Rubber Group Material
- Nitrile Rubber
- Silicone Rubber
- Nitrile Rubber
-
Usage Environment
- Standard
- Static Diffusion
- Oil Resistance
-
O.D. (d)(Ø)
-
Type
- VPCE
- VPCT
- VPDT
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
Complementary Products
-
Vacuum Fittings / Soft / Soft Bellows / Fixed / K-Shape
MISUMI Standard Price : 15.40 € Shipping Days: 5 Days
